Specification :
| SENSOR SECTION | Image Sensor | 1/2.5-type (inch) MOS Sensor | |
|---|---|---|---|
| Effective Pixles | 8.29 megapixels | ||
| LENS SECTION | F Value | F1.8 ? 4.0 | |
| Optical Zoom | 24x | ||
| Focal Length | 4.12 ? 98.9mm | ||
| 35 mm Film Camera Equivalent | 25.0 ? 600.0 mm | ||
| Filter Diameter | 62 mm | ||
| Lens Brand | Leica Dicomar Lens | ||
| CAMERA SECTION | Minimum Illumination | 1.5 lx (F1.8, Super Gain +, 1/30) | |
| Focus | Auto / Manual | ||
| Zoom | Intelligent Zoom OFF | 24x | |
| Intelligent Zoom ON | Max. 48x (UHD 32x) | ||
| Digital Zoom | 2x / 5x / 10x | ||
| Shutter Speed | 59.94 Hz mode | 59.94i/59.94p: 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500,1/2000, 1/3000, 1/4000, 1/8000 sec 29.97p: 1/30, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500,1/2000, 1/3000, 1/4000, 1/8000 sec 23.98p: 1/24, 1/48, 1/50, 1/60, 1/100, 1/120, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec | |
| 50.00 Hz mode | 50i/50p: 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec 25p: 1/25, 1/50, 1/60, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/750, 1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/8000 sec | ||
| Slow Shutter Speed | 59.94 Hz mode | 59.94i/59.94p: 1/8, 1/15, 1/30 sec 29.97p: 1/8, 1/15 sec 23.98p: 1/6, 1/12 sec | |
| 50.00 Hz mode | 50i/50p: 1/6, 1/12, 1/25 sec 25p: 1/6, 1/12 sec | ||
| Super Slow Recording Frame Rate | 59.94 Hz mode | FHD 120 fps (1/2 speed at 60p, 1/4 speed at 30p, 1/5 speed at 24p) | |
| 50.00 Hz mode | FHD 100 fps (1/2 speed at 50p, 1/4 speed at 25p) | ||
| ND Filter | 1/4, 1/16, 1/64, OFF | ||
| IR Filter | Incorporates the ON/OFF control function | ||
| White Balance | Auto / ATW LOCK / 3200K / 5600K / VAR (2000K—15000K) / Ach Fixed / Bch Fixed | ||
| Iris | Auto / Manual | ||
| Image Stabilizer | Ball O.I.S., 5-Axis HYBRID O.I.S. (UHD/FHD) | ||
| RECORDING SECTION | Recording Media | SDHC/SDXC Memory Card | |
| Recording Format | MOV, MP4, AVCHD | ||
| Video Compression Method | MOV/MP4: H.264/MPEG-4 AVC High Profile, H.265/MPEG-H HEVC Main10 Profile AVCHD: H.264/MPEG-4 AVC High Profile | ||
| Audio Compression Method | MOV: LPCM (24bit 2ch) MP4: AAC (16bit 2ch) AVCHD: Dolby Audio (16bit 2ch) | ||
| System Frequency | 59.94Hz / 50.00Hz | ||
| Recording / Playback Mode | MOV (HEVC) | [4:2:0 10bit] UHD 3840x2160 59.94p/50.00p HEVC 200M: Average 200Mbps (VBR) UHD 3840x2160 29.97p/25.00p/23.98p HEVC 150M: Average 150Mbps (VBR) | |
| MOV | [4:2:0 8bit] UHD 3840x2160 59.94p/50.00p 150M: Average 150Mbps (VBR) UHD 3840x2160 29.97p/25.00p/23.98p 100M: Average 100Mbps (VBR) [4:2:2 10bit] UHD 3840x2160 29.97p/25.00p/23.98p 150M: Average 150Mbps (VBR) FHD 1920x1080 59.94p/50.00p 200M (ALL-Intra): Average 200Mbps (VBR) FHD 1920x1080 29.97p/25.00p/23.98p 100M (ALL-Intra): Average 100Mbps (VBR) FHD 1920x1080 59.94i/50i 100M (ALL-Intra): Average 100Mbps (VBR) FHD 1920x1080 59.94p/50.00p 100M: Average 100Mbps (VBR) FHD 1920x1080 29.97p/25.00p/23.98p/59.94i/50.00i 50M: Average 50Mbps (VBR) | ||
| MP4 (HEVC) | [4:2:0 10bit] UHD 3840x2160 59.94p/50.00p HEVC 100M: Average 100Mbps (VBR) UHD 3840x2160 29.97p/25.00p/23.98p HEVC 72M: Average 72Mbps (VBR) | ||
| MP4 | [4:2:0 8bit] UHD 3840x2160 29.97p/25.00p/23.98p 72M: Average 72Mbps (VBR) FHD 1920x1080 59.94p/50.00p/23.98p 50M: Average 50Mbps (VBR) | ||
| AVCHD | [4:2:0 8bit] PS 1920x1080 59.94p/50.00p: Average 25Mbps (VBR) PH 1920x1080 59.94i/50.00i/23.98p: Average 21Mbps (VBR) HA 1920x1080 59.94i/50.00i: Average 17Mbps (VBR) PM 1280x720 59.94p/50.00p: Average 8Mbps (VBR) | ||
| P2 | — | ||
| LIVE STREAMING | Video Compression Format | H.264/MPEG-4 AVC Main Profile, High Profile | |
| Video Resolution | 1920 x 1080 (FHD), 1280 x 720 (HD), 640 x 360, 320 x 180 | ||
| Streaming Method | Unicast, Multicast | ||
| Frame Rate | System frequency = 59.94 Hz: 30 fps, 60 fps System frequency = 50.00 Hz: 25 fps, 50 fps | ||
| Bit Rate | 24 Mbps, 20 Mbps, 16 Mbps, 14 Mbps, 8 Mbps, 6 Mbps, 4 Mbps, 3 Mbps, 2 Mbps, 1.5 Mbps, 1 Mbps, 0.7 Mbps, 0.5 Mbps | ||
| Audio Compression Format | AAC-LC, 48 kHz/16 bit, 2ch | ||
| Network Protocol | RTSP/RTP/RTMP/RTMPS | ||
| STILL IMAGE SECTION | Recording Format | JPEG (DCF/Exif2.2) | |
| Recording Image Size* | Video Playback Mode: 3840 x 2160 (16:9), 1920 x 1080 (16:9), 1280 x 720 (16:9) | ||
| GENERAL SECTION | Power Supply | 7.28V (Battery) / 12V (AC Adaptor) | |
| Power Consumption | 14.4W (LCD Monitor) | ||
| Dimensions (W x H x D) | Approx. 129 x 93 x 257 mm (5.08 x 3.66 x 10.1 inch) | ||
| Weight | Body: approx. 0.9kg (1.98 lb) (body only, excluding handle, lens hood, battery, and accessories) Shooting: approx. 1.2kg (2.65 lb) (including lens hood, battery, and eyecup) | ||
| LCD Monitor | 8.88 cm (3.5-inch) Wide LCD monitor (About 2,760,000 dots) (For Europe) 3.5-inch Wide LCD monitor (About 2,760,000 dots) (For North America / Asia) | ||
| Viewfinder | 0.61 cm (0.24-inch) Wide EVF (About 1,560,000 dots) (For Europe) 0.24-inch Wide EVF (About 1,560,000 dots) (For North America / Asia) | ||
| Manual Ring | Focus / Zoom or Iris | ||
| Accessory Shoe | Yes | ||
| LED Video Light | Average Illumination | — | |
| Irradiation Angle | — | ||
| Color Temperature | — | ||
| INTERFACE SECTION | Video | SDI OUT | — |
| HDMI | Type A x 1 (VIERA Link not supported) Output format: 2160/59.94p/50.00p/29.97p/25.00p/23.98p, 1080/59.94p/50.00p/29.97p/25.00p/23.98p/59.94i/50.00i, 720/59.94p/50.00p, 480/59.94p, 576/50.00p | ||
| Audio Input | Built-in Microphone | Stereo microphone | |
| Microphone Input | 3.5mm stereo mini jack x 1 | ||
| XLR Input | — | ||
| Audio Output | SDI | — | |
| HDMI | 2 ch (LPCM 24bit) | ||
| Headphone | 3.5 mm diameter stereo mini jack x 1 | ||
| Speaker | 15 mm diameter, round x 1 | ||
| Other Input/Output | Camera Remote | 2.5mm super mini jack x 1 | |
| USB 2.0 HOST | — | ||
| USB 2.0 DEVICE | Micro-AB connector, 5-pin, mass storage function (read only) | ||
| DC IN | DC 12V (11.4V ? 12.6V) EIAJ Type4 | ||
| Wi-Fi | Standard | IEEE 802.11b/g/n | |
| Frequency | 2.4GHz band | ||
| STANDARD ACCESSORY | AC Adaptor | Yes | |
| AC Cable | Yes | ||
| Rechargeable Battery Pack | Yes (5,900mAh) | ||
| Handle Unit | — | ||
| Battery Charger | — | ||
| IR Remote | — | ||
| HDMI Cable | — | ||
| AV Cable | — | ||
| USB Cable | — | ||
| USB LAN Conversion Adaptor | — | ||
| Microphone Holder | — | ||
| Microphone Holder Screws | — | ||
| Input Terminal Cap | — | ||
| Eye Cup | Yes | ||
| Lens Hood | Yes | ||
| Editing Software | — | ||
| NOTE | NOTE | * Only images cut from video in video playback mode are supported. Specifications are subject to change without notice. | |
