Wireless Transmission System

Hollyland COSMO 600 Wireless HDMI/SDI Transmission System (L-Series)

Rp 20.500.000 Warranty: Garansi Resmi 1 Tahun

Specification :

  • Product Include :
  • - Hollyland Transmitter
  • - Receiver
  • - 3x 5GHz Antennas
  • - Magic Arm
  • - Crab Clamp
  • - 2x D-Tap to Lemo Cable
  • - Hard Case
  • - User Manual
  • - Hollyland Warranty
  • Product Highlights :
  • HDMI/SDI Input, SDI Loop, 3.5mm Audio
  • HDMI/Dual SDI Outputs
  • 600' 1080p60 Transmission, <1 ms Latency
  • 5.1-5.9 GHz Frequency Band




Ingin cicilan 0% ? Silahkan klik :

lazada.co.id tokopedia.com blibli.com shoope.co.id bukalapak.com jd.id elevania.com


In a lighter, slimmer design than the COSMO 400, the Hollyland COSMO 600 allows you to transmit an HDMI/SDI signal up to 600' to an HDMI or dual SDI outputs. The transmitter/receiver set supports up to 1080p60 signals with a latency of <1 ms. The transmitter also offers an SDI loop-through out and 3.5mm stereo audio input. The system operates on the 5.1 to 5.9 GHz frequency band and uses AES-128 encryption for secure live delivery of your video. Other features include an OLED screen on both units, timecode, and automatic synchronization with camera recording.

The transmitter and receiver both feature an L-series battery plate. Additionally, D-Tap to LEMO cables are included for powering both devices off compatible batteries. The transmitter uses two antennas while the receiver has a built-in antenna. Three highly flexible antennas that are less disposed to accidental damage are supplied for the transmitter, one as a spare, and two mushroom antennas are also provided as replacements for the standard ones.

  • Transmit up to a 1080p60 HDMI/SDI signal to an HDMI or dual SDI outputs
  • 600' line-of-sight transmission with <1 ms latency
  • SDI loop-through out
  • 3.5mm stereo audio input
  • 5.1-5.9 GHz frequency band
  • AES-128 encryption
  • OLED screen
  • Timecode
  • Automatic synchronization with camera recording
  • L-series battery plates
  • D-Tap to LEMO cables
Transmitter
Transmission Range600' / 183 m Line-of-Sight
Latency<1 ms
Connections1 x HDMI Type A Input
1 x 3G/HD/SD-SDI Input
1 x 3G/HD/SD-SDI Loop-Through Out
Input Resolution1080p: 60/59.94/50/30/29.94/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
480p: 60
576p: 50

3G/HD/SD-SDI Auto-Selected, SMPTE-259/274/292/296/372/424/425
Supported Audio1 x 3.5 mm Stereo Input
Embedded 2-Channel 24-Bit/48 kHz
Frequency5.1-5.9 GHz
Antenna Support2 x RP-SMA Male Ports
ModulationOFDM 16QAM
Transmission Power17 dBm Max
Bandwidth40 MHz
EncryptionAES-128 Encryption
DisplayOLED
Firmware UpgradableMini-USB Port
Battery PlateL-Series
Power Input Connection4-Pin LEMO, Female
Power Input7-36 VDC
Power Consumption<6 W
Operating Temperature32 to 104°F / 0 to 40°C
Storage TemperatureNot Specified by Manufacturer
Dimensions5 x 2.75 x 1" / 12.7 x 7 x 2.5 cm (Not Including Antennas)
Weight9.2 oz / 260 g
Receiver
Transmission Range600' / 183 m Line-of-Sight
Latency<1 ms
Output1 x HDMI Type A Output
2 x 3G/HD/SD-SDI
Output Resolution1080p: 60/59.94/50/30/29.94/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
480p: 60
576p: 50

3G/HD/SD-SDI Auto-Selected, SMPTE-259/274/292/296/372/424/425
Supported AudioEmbedded 2-Channel 24-Bit/48 kHz
Frequency5.1-5.9 GHz
AntennaBuilt In
ModulationOFDM 16QAM
Receiver Sensitivity-75 dBm
Bandwidth40 MHz
EncryptionAES-128 Encryption
DisplayOLED
Firmware UpgradableMini-USB Port
Battery PlateL-Series
Power Input Connection4-Pin LEMO, Female
Power Input7-36 VDC
Power Consumption<8 W
Operating Temperature32 to 104°F / 0 to 40°C
Storage TemperatureNot Specified by Manufacturer
Dimensions6.3 x 3.7 x 1" / 15.9 x 9.4 x 2.5 cm
Weight1 lb / 460 g
Packaging Info
Package Weight8.9 lb
Box Dimensions (LxWxH)16 x 12.75 x 6"
