Specification :
| Model | PavoTube II 30C |
| Rated Power | 60W |
| Input Voltage/Current | DC15V/4A Max, AC100-240V 50/60Hz PD3.0(12-20V)30W Min |
| CCT | 2700K-7500K(G/M±150) |
| CRI | Average 97 |
| TLCI | Average 98 |
| TM-30 Rf | Average 94 |
| TM-30 Rg | Average 101 |
| Dimming | 0-100% |
| Control | On-board, Remote Controller, NANLINK APP, DMX/RDM |
| Effect | Hue Loop, CCT Loop, INT Loop, CCT Flash, HUE Flash, CCT Pulse, Hue Pulse, Storm Auto, Police Car, TV, Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion and Welding |
| Product Size | φ48×1170mm/φ1.89×46.06" |
| Product Weight | Light Fixture: 1.4kg / 3.09lb Power Adapter: 0.2kg / 0.44lb Power Cable 3M: 0.05kg / 0.11lb |
| Master Carton Size | 455 × 305 × 1300mm / 17.91 × 12.01 × 51.18" (1KIT) 305 × 305 × 1300mm / 12.01 × 12.01 × 51.18" (2KIT) 375 × 190 × 1300mm / 14.76 × 7.48 × 51.18" (4KIT) |
| Quantity of Boxes Per Carton | 1KIT: 8 / 2KIT: 6 / 4KIT: 2 |
| Certification | CE, UKCA, RoHS, PSE, KCC, FCC-ID, NCC, KC |
| Model | PavoTube II 30C | |||
|---|---|---|---|---|
| Distance | 0.5M | 1M | 2M | 3M |
2700K | 1720 lux /160 fc | 581 lux /54 fc | 174 lux /16 fc | 88 lux /8 fc |
3200K | 1767 lux /164 fc | 599 lux /56 fc | 179 lux /17 fc | 90 lux /8 fc |
5600K | 1910 lux /177 fc | 647 lux /60 fc | 193 lux /18 fc | 97 lux /9 fc |
6500K | 1944 lux /181 fc | 660 lux /61 fc | 196 lux /18 fc | 99lux /9 fc |
7500K | 1925 lux /179 fc | 654 lux /61 fc | 195 lux /18 fc | 98 lux /9 fc |
R | 870 lux /81 fc | 303 lux /28 fc | 88 lux /8 fc | 43 lux /4 fc |
G | 1819 lux /169 fc | 642 lux /60 fc | 181 lux /17 fc | 91 lux /8 fc |
B | 300 lux /28 fc | 106 lux /10 fc | 30 lux /3 fc | 16 lux /1 fc |
