Specification
General
Name
Vimble 3 Smartphone Gimbal Stabilizer
Demensions
Unfolded: 300.7*130.7*87.5mm
Folded: 114.4*175.6*64.6mm
Weight
About 387 g/0.853 lbs (Without tripod)
Material of Main Body
PA6, ABS+PC
Phone Width Range
49-88 mm/1.93-3.46 inches
Maximum Phone Thickness
12.5 mm/0.49 inches
Maximum Payload
Up to 260 g/0.573 lbs (After balanced).
Water Proof
Splash-proof
Gimbal
Stabilization
3-axis Motor
Controllable Range
Tilt:+35°~-35°
Roll:+50°~-50°
Pan:-80°~+174°
Rotatable Range
Tilt: 320°(With limitation)
Roll: 337°(With limitation)
Pan: 321°(Unlimited)
Extended Ports
At the bottom of the handle:
1/4 inch thread hole*1, which can mount Tripod
At the right side of handle:
Type-C charging port*1;
At the right side of smartphone holder:
Type-C extension port*1 to connect accessories
Battery
Type
Lithium Cell
Capacity
1300mAh, built-in battery cannot be removed, charge it via the USB-C port on the right side of handle, do not support quick charger.
Theoretical Battery Life
About 10h
Operating Voltage
6.8V-8.4V
Operating Temperature
-10°~ 45°
Charging Time
About 2.5 hours.
The status indicator is red while charging, and turns green after fully charged.
APP
Name
Feiyu ON
Required Operating System
iOS 9.0 or later
Android 6.0 or later
How to Control The Smartphone
After connect the gimbal with your smartphone via Bluetooth, the gimbal can directly control photo/video on smartphone original camera. And you can find more creative shooting modes in Feiyu On App, such as AI tracking, Gesture Control, Dolly Zoom, Slow Motion, Panorama and Trajectory Time-lapse.
Extension Rod
The extension rod could be extended and retractable for selfie no matter whether Vimble 3 is on or off.
Usage:
(1) Hold the handle with one hand, and hold the bottom of pan axis with the other hand after unfolding the gimbal.
(2) Extend: Pull the extension rod out to suitable length (Extendable range 0~198mm).
(3) Reset: Push upper grip to make the extension rod down to handle part.
*Do not rotate the rod to extend or reset.
Optional Accessories
Feiyu Magnetic Fill Light for Smartphone Gimbals;
Feiyu Magnetic Fill Light 2 for Smartphone Gimbals;
Feiyu Intelligent Tracking Module;
Other Available Functions For Users
1. Users can manually lock the tilting angle to fit any shooting angle needs.
2. Users can initialize the gimbal to adjust the oblique working status or abnormal working status to reacquire the correct pose data.
