Specification :
Pure Ease for the Here and Now
Regardless of whether it’s manual or fully automatic, the intuitive Leica D-Lux 8 lets you capture the moment before it slips away. You can shoot and share with pure emotion thanks to its ergonomic design, intuitive layout, touchscreen, high-resolution OLED viewfinder and optical zoom.
The D-Lux 8 lets you create images with unmistakable aesthetics – while travelling, in street photography or with friends and family. This compact camera features the iconic Leica design, fits in any pocket and is incredibly easy to use.
Fast Zoom Lens
Ranging from 24 mm to 75 mm, the Leica DC Vario-Summilux 10.9–34 f/1.7–2.8 ASPH. covers all the key focal lengths for landscape and portrait photography. You can select the subject flexibly and capture any situation with spontaneity and precision. The fast lens speed starting at an aperture of f/1.7 allows you to shoot in difficult lighting conditions and deliberately compose images with focus and blur. The optional automatic lens cap ensures that your camera is always ready for action – making it an innovative and extremely practical accessory for your Leica D-Lux 8.
High Resolution and Creative Post-Processing
The powerful 4/3″ CMOS sensor with 21 MP (effectively 17 MP) offers high image quality characterised by natural colours and clear details. Expressive and authentic imagery can be composed in either the JPEG or DNG format. For digital RAW files in DNG format, you benefit from the greatest flexibility when it comes to post-processing. Record videos with the D-Lux 8 in up to 4K quality at 30 frames per second or in Full HD at 60 frames per seconds.
Show Your Subject in the Best Light
The D-Lux 8 comes with a small yet powerful clip-on flash. This allows you to improve your compositions when shooting in low light, reduce shadows in portraits and experiment with second curtain sync. This technique lets you capture creative, dynamic images with a truly distinctive look.
Leica FOTOS App
With the Leica FOTOS App, you can transfer your pictures directly to your smartphone, edit them and share them in no time. This puts you in full command of your images, and you can even control your camera remotely if required.
| Camera type | Digital compact camera |
| Dimensions (WxHxD) | 130 x 69 x 62 mm |
| Weight | Approx. 397 g/357 g (with/without battery) |
| Sensor size | 4/3“ CMOS sensor, 21,77 MP/17 MP (total/effective) |
| Buffer | DNG™: 14 or higher*, JPG: 100 or higher* *Based on CIPA standards and a memory card with high read/write speed. Capacity, depending on frame rate and picture format, estimated quantity (number of possible images in the buffer memory) |
| Storage medium | UHS-II (recommended), UHS-I, SD/SDHC/SDXC memory card |
| Material | Full metal housing: magnesium die-cast, leatherette covering |
| Lens | Leica DC Vario-Summilux 10.9–34 f/1.7–2.8 ASPH. (35 mm equivalent: 24–75 mm) aperture range: 1.7–16/2.8–16 (at 10.9/34 mm) |
| Lens filter thread | E43 |
| Aperture range | Depending on zoom level, F1.7 to F16 in 1⁄3 EV increments (wide angle) F1.7 to F16; (tele zoom) F2.8 to F16 in 1/3 EV increments |
| Operating conditions | 0°C to +40°C |
| Interfaces | ISO accessory shoe with additional control contacts for Leica flash units, HDMI jack Type D, USB 3.1 Gen 1 Type C |
| Tripod thread | A 1⁄4 DIN 4503 (1⁄4”) with stainless steel in the base |
| Image stabilization | Visual compensation system for photos and video recordings |
| Filter | RGB color filter, UV/IR filter |
| File formats | Photo: DNG™ (raw data), DNG + JPG, JPG (DCF 2.0, Exif 2.31) Video: MP4, H.264, AAC stereo |
| Photo resolution |
|
| DNG™ | 16:9 - 5152 x 2904 (15 MP) 3:2 - 4928 x 3288 (16.2 MP) 4:3 - 4736 x 3552 (16.8 MP) 1:1 - 3552 x 3552 (12.6 MP) |
| L-JPG | 16:9 - 5152 x 2904 (15 MP) 3:2 - 4928 x 3288 (16.2 MP) 4:3 - 4736 x 3552 (16.8 MP) 1:1 - 3552 x 3552 (12.6 MP) |
| M-JPG | 16:9 - 3840 x 2160 (8.3 MP) 3:2 - 3504 x 2336 (8.2 MP) 4:3 - 3360 x 2520 (8.5 MP) 1:1 - 2528 x 2528 (6.4 MP) |
| S-JPG | 16:9 - 1920 x 1080 (2.1 MP) 3:2 - 2496 x 1664 (4.2 MP) 4:3 - 2368 x 1776 (4.2 MP) 1:1 - 1776 x 1776 (3.2 MP) |
| File size | |
| DNG™ | approx. 31 MB, depending on resolution and image content |
| JPG | depending on resolution and image content |
| Video | max. length: 29 min |
| Color depth | |
| DNG™ | 12 bit |
| JPG | 8 bit |
| Color space | Photo: sRGB |
| Video Resolution | |
| 4K | 3840 x 2160 |
| Full HD | 1920 x 1080 |
| HD | 1280 x 720 |
| Video frame rate/bit rate | |
| 4K 30 p | 29.97 fps - 4K 4:2:0 / 8 bit - h.264 L-GOP 100 Mbps |
| 4K 24 p | 23.98 fps - 4K 4:2:0 / 8 bit - h.264 L-GOP 100 Mbps |
| FHD 60 p | 59.94 fps - FHD 4:2:0 / 8 bit - h.264 L-GOP 28 Mbps |
| FHD 30 p | 29.97 fps - FHD 4:2:0 / 8 bit - h.264 L-GOP 20 Mbps |
| HD 30 p | 29.97 fps - HD 4:2:0 / 8 bit - h.264 L-GOP 10 Mbps |
| Viewfinder/LCD panel | |
| Viewfinder (EVF) | OLED, Resolution: 2,360,000 dots, 60 fps, magnification: 0.74x, at aspect ratio: 4:3, exit pupil position: 20 mm, setting range -4/+4 dpt, with eye sensor for automatic switchover between viewfinder and LCD panel, time delay 0.005 s |
| LCD panel | 3” TFT LCD, approx. 1,843,200 dots, 384 ppi, aspect ratio 3:2, touch panel |
| Shutter | |
| Shutter type | Mechanical central shutter or optional electronic shutter |
| Shutter speeds | Mechanical shutter: 60 s to 1⁄4000 s Electronic shutter function: 1 s to 1⁄16000 s |
| Shutter button | Two-stage (1st stage: Activation of the camera electronics including autofocus and exposure metering, 2nd stage: Taking the picture) |
| Self-timer | Delay time: 2 s or 12 s |
| Drive Mode | ?Single?, ?Interval Shooting?, ?Exposure Bracketing? Continuous shooting: |
| Focusing | |
| Focus range | 50 cm to ∞ With macro setting: from 3 cm (wide angle), from 30 cm (tele zoom) |
| Focus mode | Automatic, Automatic (macro), or Manual |
| Autofocus system | Contrast detection |
| Autofocus modes | ?Intelligent AF? (autonomously selects ?AFs? and ?AFc?), ?AFs?, ?AFc? |
| Autofocus metering methods | ?Spot? (can be shifted), ?Field? (can be shifted and scaled), ?Multi-Field?, ?Zone? (can be shifted), ?Eye / Face?, Tracking? |
| Autofocus metering fields | 49 |
| Exposure | |
| Exposure metering | TTL (exposure metering through the lens), with working aperture |
| Metering principle | Exposure metering is done by the image sensor for all exposure metering methods |
| Exposure metering methods | ?Spot?, ?Center-Weighted?, ?Multi-Field? |
| Exposure modes | Program AE mode (P) Aperture-priority mode (A): manual aperture setting Shutter-priority mode (S): manual shutter-speed setting Manual (M): manual setting for shutter speed and aperture Various fully automatic variants (?Scene Mode?): ?Auto?, ?Portrait?, ?Landscape?, ?Night Scenery?, ?Miniature Effect?, ?One Point Color?, ?HDR? |
| Exposure compensation | ±3 EV in 1⁄3 EV increments |
| Automatic bracketing | 3, 5 or 7 frames, graduations between shoots up to 1 EV, in 1⁄3 EV increments additional optional exposure compensation: up to ±3 EV |
| ISO sensitivity range | |
| ?Auto ISO? | Photo ISO 100–ISO 25 000 | Video ISO 100–ISO 6 400 |
| Manual | Photo ISO 100–ISO 25 000 | Video ISO 100–ISO 6 400 |
| White balance | Automatic (?Auto?), default (?Daylight?, ?Cloudy?, ?Shadow?, ?Tungsten?, ?Flash?), manual metering (?Gray Card?), manual color temperature settings (?Color Temperature?, 2500 K to 10000 K) |
| Flash | |
| Flash unit | Included in the delivery: Leica CF D |
| Flash angle | Aligned with the shortest focal length of the lens of 10.9 mm |
| Guide number | 10/7 (at ISO 200/100) |
| Flash range | Approx. 0.6–14.1 m/0.3–8.5 m (at shortest/longest focal length) |
| Flash unit connector | Via the accessory shoe |
| Flash sync time | : 1⁄4000 s, slower shutter speeds available |
| Flash exposure compensation | ±3 EV in 1⁄3 EV increments |
| Equipment | |
| Microphone | Stereo |
| Speaker | Mono |
| WLAN | WLAN function for connecting to the Leica FOTOS app. The Leica app is available from the Apple App Store™ or the Google Play Store™. IEEE802.11b/g/n Channel 1–11 (2412–2462 MHz), maximum output (e.i.r.p.): 5.9 dBm, encryption method: WLAN-compatible WPA™/WPA2™ |
| Bluetooth | Bluetooth 5.0 LE: Channel 0–39 (2402–2480 MHz), maximum output (e.i.r.p.): 1.2 dBm |
| GPS | Not available everywhere due to country-specific legislation; can be added via the Leica FOTOS app. Data is written to Exif header of the picture files. |
| Menu languages | English, German, French, Italian, Spanish, Portuguese, Russian, Japanese, Traditional Chinese, Simplified Chinese, Korean |
| Power supply | |
| Rechargeable battery (Leica BP-DC15) | Lithium-ion rechargeable battery, rated voltage: 7.2 V (DC), capacity: 1025 mAh (min.), manufacturer: Panasonic Energy (Wuxi) Co. Ltd., Made in China |
| Charging via USB | With camera switched off: 5 V/1500 mA (2.5 W or greater) |
| Rated values for input voltage/power | 7.2 V 0.9 A (battery), 5 V 1.0 A (USB) |
