Sony HXR-NX800 4K HDR NXCAM Handheld Camcorders

Camera Type

Solid-state memory camcorder

Mass (Main Body Only)

Approx. 1930 g (4 lb 4.1 oz.)

Mass (Including Supplied Accessories and Battery)

Approx. 2380 g (5 lb 4.0 oz.) *1

Dimensions (W x H x D)

Approx. 175.6 x 201.3 x 371.1 mm (7 inch x 8 inch x 14 5/8 inch)

Battery

BP-U35, BP-U70, BP-U100

Battery

Yes (Available with USB Type-C Terminal. USB Power Delivery compatible)

Power Requirements

DC 19.5 V

Normal Power Consumption

16 W

Maximum Power Consumption

Approx. 32 W

Operating Temperature

0 to 40 ? (32 to 104 ?)

Storage Temperature

-20 to 60 ? (-4 to 140 ?)

Battery Operating Time (Continuous Shooting)

120 minutes*2

Recording Format (Video)

XAVC S: MPEG-4 AVC / H.264
XAVC HS: MPEG-H HEVC / H.265

Zoom Ratio

20x

Focal Length

f=7.71-154.21 mm

Focal Length (35mm Format Equivalent)

24-480 mm

Iris (Maximum Apertures)

F2.8-F4.5

Focus Range (From the front of the Lens)

Approx. 1 cm (0.03 ft) to ∞ (wide)
Approx. 100 cm (3 ft) to ∞ (telephoto)

Filter Diameter

72 mm

Imaging Device (Type)

1.0-type (13.2 mm x 8.8 mm) Exmor RS CMOS sensor

Number of Pixels (Total)

Approx. 20.9 megapixels

Number of Pixels (Effective)

Approx. 14.0 megapixels max.*3

Built-in ND Filter

Linear variable ND (1/4 ND - 1/128 ND)

Minimum Illumination

1.2 lx (typ)*4

RAW Output

Optical Low Pass Filter

Yes

Shutter Type

Electronic shutter

Shutter Speed

1/8000 sec to 64F

Slow & Quick Motion (S&Q)

Yes

White Balance

2000 K - 15000 K

Gain

-3 to 36 dB (Every 1 dB)

Base Look

S-Cinetone, ITU709, 709tone, s709, 709(800%), S-Log3, HLG(Live / Mild / Natural)

Image Stabilization (Type)

Lens-shift mechanism and electronic

Image Stabilization (Mode)

Active / Standard / Off

Lens Compensation

Peripheral Shading, Chromatic Aberration, Distortion

ISO Sensitivity

ISO 250-16000 equivalent (Using SDR Reset look), AUTO (ISO 250-16000, selectable lower limit and upper limit)

Focus Type

Fast Hybrid AF (Phase-detection AF / contrast-detection AF)

Focus Point

Max. 475 points (Phase-detection AF)

Focus Recognition Target

Human

Other Focus Features

AF Subj. Shift Sensitivity, AF Transition Speed, AF Assist

Proxy Recording

Yes

Clear Image Zoom

Approx. 1.5x (4K), approx. 2x (HD)

Audio Input

3.5 mm Stereo minijack, XLR 3-pin (Female) x2

Multi Interface Shoe

Yes (With Digital Audio Interface)

Built-In Microphone

Built-in, stereo

Headphone Terminal

Yes (3.5 mm Stereo minijack)

Built-In Speaker

Built-in, monaural

Recording System (Audio)

LPCM 4ch (48 kHz 24 bit)

SDI Output

HDMI Output

HDMI connector (Type-A)

TC / UB

Yes

Timecode Input / Output

Genlock Input

Multi / Micro USB Terminal

USB Terminal

Yes (SuperSpeed USB 5 Gbps (USB 3.2) compatible)

DC Input

Yes

Remote

Yes (2.5 mm Stereo mini-mini jack)

Remote (Wireless)

Yes (Bluetooth remote control)

Wired LAN

Yes (1000BASE-T, 100BASE-TX, 10BASE-T)

Wireless LAN (Built-In)

Yes (Wi-Fi Compatible, IEEE 802.11a / b / g / n / ac (2.4 GHz band / 5 GHz band))*5*6

PC Interface

Mass-storage / MTP

Other Function

FTP Transfer Func. (Wired LAN (USB-LAN), USB Tethering, Wi-Fi)

Type (Viewfinder)

1.0 cm (0.39-type) electronic viewfinder (XGA OLED)

Number of Dots (Viewfinder)

2 359 296 dots

Magnification (Viewfinder)

Approx. 1.07x*7 with 50 mm lens at infinity,-1 m-1

Diopter Adjustment (Viewfinder)

-4.0 to +3.0 m-1

Eye Point (Viewfinder)

Approx. 22 mm from the eyepiece lens, at -1 m-1 *8

Type (LCD Screen)

8.8 cm (3.5-type) type TFT

Touch Panel (LCD Screen)

Yes

Number of Dots (Total) (LCD Screen)

2 764 800 dots

Type

SLOT A: Multi slot for SD (UHS-I / II compliant) memory card / CFexpress Type A card
SLOT B: Multi slot for SD (UHS-I / II compliant) memory card / CFexpress Type A card

NFC

Protocols

RTMP, RTMPS, SRT

Video Data Format

MPEG-4 AVC / H.264
MPEG-H HEVC / H.265

Video Resolution

3840 x 2160 (Using RTMP / RTMPS), 1920 x 1080, 1280 x 720

Audio Data Format

AAC-LC 2ch (16bit 48 kHz)

Accessibility Functions

Enlarge Screen, Screen Reader

Supplied Accessory

AC adaptor, Power cord, Battery charger, Rechargeable Battery, LCD hood, Lens hood, Eyecup, Microphone holder, Cold shoe kit

When attaching lens hood, LCD hood, microphone holder, eyecup and BP-U35.

Using BP-U35, normal power consumption.

The number of effective pixels will vary depending on the shooting mode and settings.

3840 x 2160 / 29.97p mode, F2.8, +36 dB gain, SS=1/30 (sec), BaseLook=ITU709.

(Configuration method / Access method) WPS or manually / infrastructure mode. When connecting to smartphones, the camera can always work as a base without a wireless access point. (Security: WEP / WPA-PSK / WPA2-PSK / WPA3-SAE)

The model shipped to countries with legal restrictions on 5 GHz band communication does not support 5 GHz communication. Please check the regulations in your country or region.

35 mm camera equivalent.

CIPA standard.

Design and specifications are subject to change without notice.
