Diagram yang menampilkan mekanisme gimbal internal, dengan ilustrasi penjelasan yang menampilkan gimbal konvensional

Meredam guncangan - Mekanisme Gimbal di Dalam

Pelajari lebih lanjut

Gambar gedung dan jembatan dengan detail tinggi

Perekaman 4K resolusi tinggi

Pelajari lebih lanjut

Subjek yang bergerak cepat (misalnya penari)

AF performa tinggi

Pelajari lebih lanjut

Gambar adegan perekaman suara, dengan musisi jalanan ditampilkan pada layar LCD AX43A

Rekaman suara yang terdengar luar biasa alami

Pelajari lebih lanjut

Gambar pengambilan gambar selfie dengan AX43A, mikrofon shotgun dan genggam opsional

Ideal untuk pembuat konten dan videografer

Pelajari lebih lanjut

Sekelompok muda-mudi bersenang-senang di pantai

Efek khusus, agar film berdampak tinggi

Pelajari lebih lanjut

Pengambilan gambar ekstra stabil ketika bergerak

Lihat Balanced Optical SteadyShot beraksi

Stabil saat berjalan

Penstabil unik Balanced Optical SteadyShot, dengan mekanisme gimbal internal, sekitar 13 kali lebih efektif daripada sistem optik lainnya memungkinkan pemotretan bebas guncangan saat berjalan.

Stabil bahkan saat berlari

Mekanisme gimbal internal dan algoritme pemroses gambar Balanced Optical SteadyShot menghasilkan pemotretan yang stabil sehingga Anda bahkan dapat merekam film stabil sambil berlari.

Stabil pada zoom penuh

Stabilitas yang diberikan gimbal dan algoritme Balanced Optical SteadyShot memungkinkan Anda untuk merekam film stabil bahkan saat zoom penuh ketika guncangan kamera paling terlihat.

Sensor

SENSOR TYPE: 1/2.5 type (7.20 mm) back-illuminated Exmor R CMOS Sensor
EFFECTIVE PIXELS (VIDEO): approx. 8.29 Megapixels (16:9)

EFFECTIVE PIXELS (STILL IMAGE): approx. 8.29 Megapixels (16:9) / approx. 6.22 Megapixels (4:3)

Processor

IMAGE PROCESSOR: BIONZ X image processor

Lens

LENS TYPE: ZEISS Vario-Sonnar T*
FILTER DIAMETER: 55 mm
LENS COVER: Auto
APERTURE: F2.0-3.8
FOCAL DISTANCE: f=4.4-88 mm

FOCAL LENGTH (35MM EQUIVALENT) (VIDEO): f=1 1/16-21 1/8 inch , f=26.8-536.0 mm (16:9)
FOCAL LENGTH (35MM EQUIVALENT) (STILL IMAGE): f=1 1/16-21 1/8 inch (16:9), f=1 5/16-25 7/8 inch (4:3), f=26.8-536.0 mm (16:9), f=32.8-656.0 mm (4:3)
MINIMUM FOCUS DISTANCE: approx. 1 cm (Wide), approx. 80 cm (Tele), approx. 13/32 inch (Wide), approx. 31 1/2 inch (Tele)
IRIS DIAPHRAGM: 6 blades
ND FILTER: -

Zoom

OPTICAL ZOOM: 20x
CLEAR IMAGE ZOOM: 4K: 30x, HD: 40x

DIGITAL ZOOM: 250x

Viewfinder

VIEWFINDER TYPE: -
FIELD OF VIEW: -

DIOPTER ADJUSTMENT: -

LCD

SCREEN TYPE: 7.5 cm (3.0 type) Xtra Fine LCD™ display (921 600 dots) Wide (16:9)
TOUCH PANEL: Yes
BRIGHTNESS CONTROL: Yes (Menu)

MARKER/GRID DISPLAY: Grid Line
ANGLE ADJUSTMENT: Opening Angle: max. 90 deg., Turning Angle: max. 270 deg.

Image Stabilisation

IMAGE STABILISATION TYPE: Balanced Optical SteadyShot w/ Intelligent Active mode (5-axis)

Focus

FOCUS TYPE: Contrast AF
FOCUS POINTS: -
FOCUS MODE: Auto / Manual (Touch Panel)
FOCUS AREA: Full range Focus / Spot Focus

FAST INTELLIGENT AF: Yes
LOCK-ON AF: Lock-on AF
MANUAL FOCUS ASSIST: Peaking Display

Exposure

MODE: Auto, Flexible Spot (Touch Panel), Manual (Menu)
METERING MODES: Multi-segment / Spot
EXPOSURE COMPENSATION: AE Shift (Touch Panel)
LOW LUX MODE: Yes
AUTO IRIS CONTROL: F2.0-F11
MANUAL IRIS CONTROL: F2.0-F11

MANUAL EXPOSURE ASSIST: Zebra Pattern Display
BACKLIGHT COMPENSATION: Yes (Auto)
GAIN CONTROL: Auto
AGC LIMIT: Yes
MINIMUM ILLUMINATION: 4K: Standard: 9 lux (1/50 Shutter Speed), HD: Standard: 6 lux (1/50 Shutter Speed), 4K: Low Lux 1.8 lux (1/25 Shutter Speed), HD: Low Lux 1.2 lux (1/25 Shutter Speed)

Shutter Speed

AUTO CONTROL RANGE: 1/6-1/10000
STANDARD: 1/50-1/10000
MANUAL IRIS CONTROL?(PHOTO MODE): 1/25-1/10000

MANUAL SHUTTER: 1/6-1/10000
SMOOTH SLOW: 1/215-1/10000

White balance

WHITE BALANCE MODES: Auto / Onepush / Outdoor / Indoor

WHITE BALANCE SHIFT: Yes

Flash

FLASH METERING SYSTEM: Pre-flash TTL
FLASH COMPENSATION: Yes (3 steps)

FLASH MODE: Auto / On / OFF

Storage Media

MEDIA TYPE: XAVC S 4K (100Mbps): SDHC Memory Card (4GB or over, UHS-I U3 or Higher) / SDXC Memory Card (UHS-I U3 or Higher), XAVC S 4K (60Mbps): SDHC Memory Card (4GB or over, Class10 or Higher) / SDXC Memory Card (Class10 or Higher), XAVC S HD: SDHC Memory Card (4GB or over, Class10 or Higher) / SDXC Memory Card (Class10 or Higher), AVCHD, Still: Memory Stick PRO Duo (Mark 2), Memory Stick PRO-HG Duo, Memory Stick XC-HG Duo, SD / SDHC / SDXC Memory Card (Class 4 or Higher)

INTERNAL MEDIA: -

Recording

RECORDING FORMAT (VIDEO): XAVC S format: MPEG4-AVC / H.264, AVCHD format ver.2.0 compatible: MPEG4-AVC / H.264, MP4: MPEG-4 AVC / H.264
VIDEO RESOLUTION: XAVC S 4K: 3840x2160 / 25p,24p, XAVC S HD: 1920x1080 / 50p,25p,24p, AVCHD: 1920x1080 / 50p(PS),25p(FX,FH),24p(FX,FH),50i(FX,FH), 1440x1080 / 50i(HQ,LP), MP4: 1280x720 / 25p
VIDEO RECORDING RATE (ABR / VBR): XAVC S 4K: approx. 100 Mbps, XAVC S 4K: approx. 60 Mbps, XAVC S HD: approx. 50 Mbps, AVCHD PS: approx. 28 Mbps / FX: approx. 24 Mbps / FH: approx. 17 Mbps / HQ: approx. 9 Mbps / LP: approx. 5 Mbps, MP4: approx. 3 Mbps
RECORDING FORMAT (STILL IMAGE): JPEG (DCF Ver.2.0 compatible, Exif Ver.2.3 compatible, MPF Baseline compatible)
STILL IMAGE SIZE (PHOTO MODE): L: 16.6 Megapixels 16:9 (5440x3056), 12.5 Megapixels 4:3 (4080x3056), M: 8.3 Megapixels 16:9, (3840x2160), 6.2 Megapixels 4:3 (2880x2160), S: 2.1 Megapixels 16:9 (1920x1080), 0.3 Megapixels 4:3 (640x480)

STILL IMAGE SIZE (MOVIE MODE): M: 8.3 Megapixels 16:9 (3840x2160), S: 2.1 Megapixels 16:9 (1920x1080)
STILL IMAGE SIZE (PHOTO CAPTURE): XAVC S 4K: 8.3 Megapixels 16:9 (3840x2160), XAVC S HD: 2.1 Megapixels 16:9 (1920x1080), AVCHD: 2.1 Megapixels 16:9 (1920x1080)
STILL IMAGE SIZE (TIME-LAPSE CAPTURE): 4K: L (8.3 M: 3840x2160) / HD: S (2.1 M: 1920x1080)
STILL IMAGE SIZE (DUAL RECORD): M: 8.3 Megapixels 16:9 (3840x2160), S: 2.1 Megapixels 16:9 (1920x1080)

Audio

MICROPHONE: Built-in Zoom Microphone
AUDIO RECORDING FORMAT: LPCM 2ch (48 kHz / 16 bit), Dolby Digital 5.1ch, Dolby Digital 5.1 Creator, Dolby Digital 2ch Stereo, Dolby Digital Stereo Creator, MPEG-4 AAC-LC 2ch
MIC LEVEL CONTROL: Yes (31 steps)

AUTO WIND NOISE REDUCTION: Yes (On / Off)
MY VOICE CANCELING: Yes
SPEAKER: Built-in Zoom Microphone, Monaural Speaker

Advanced Feature

HIGH SPEED REC: Yes (100p / 1920x1080, 100 / 60 Mbps)
TIME-LAPSE CAPTURE: Time-Lapse Capture, Shooting Interval (1/2/5/10/30/60sec), Shot Number (1-999), Capture Image Size (4K: L (8.3M, 3840x2160) / HD: S(2.1M, 1920x1080)), AE Mode (AE Lock / AE Tracking)
SCENE SELECTION: Auto / Night Scene / Sunrise & Sunset / Fireworks / Landscape / Portrait / Spotlight / Beach / Snow

NIGHTSHOT INFRARED SYSTEM: -
TIME CODE/USER BIT: Yes
OTHER FEATURES: Face Detection , Cinematone, Golf Shot (Yes), Smooth Slow Rec (Yes), Fader Effect(s) (White / Black), Intelligent Auto (Portrait / Baby / Walk / Tripod / Backlight / Landscape / Spotlight / Twilight / Macro / Low light / Auto wind noise reduction), Smile Shutter (Off / Dual Capture / Always On), Red Eye Reduction, Direct Copy

Playback

FAST PLAYBACK: About 5 times /10 times / 30 times / 60 times
SLOW PLAYBACK: Forward: 1/5 speed, Reverse: 1/2 speed
TRIMMING PLAYBACK: Yes

HIGHLIGHT MOVIE MAKER: Highlight Movie Maker, Highlight background music (Preinstalled 6 music files, Music transfer compatible)
MOTION SHOT VIDEO: Yes
SLIDE SHOW (STILL IMAGE): Slide Show

Projector

LIGHT OUTPUT: -
RESOLUTION OUTPUT: -
PROJECTED IMAGE SIZE: -

ENDURANCE (BATTERY LIFE): -
PROJECTOR INPUT: -
KEYSTONE ADJUSTMENT: -

Wireless Function

WI-FI®: Yes (Wi-Fi Compatible, IEEE 802.11b/g/n (2.4GHz band))
NFC™: Yes (NFC forum Type 3 Tag compatible)

MULTI CAMERA CONTROL: Yes

Terminal / Shoe

ACCESSORY SHOE: Yes (Multi Interface Shoe)
HDMI TERMINAL: Yes (HDMI micro)
PROJECTOR INPUT: -
MULTI/MICRO USB TERMINAL: Yes
REMOTE TERMINAL: Integrated into Multi / Micro USB Terminal

STD OUTPUT: Composite Video Out (AV CABLE (sold separately))
MICROPHONE INPUT: Stereo Minijack
HEADPHONE JACK: Stereo Minijack
MEMORY CARD SLOT: Memory Stick PRO Duo and SD / SDHC / SDXC compatible
DC IN: Yes

Power

BATTERY TYPE: InfoLITHIUM with AccuPower^TM Meter System (V Series)
POWER CONSUMPTION (LCD): 4K: 5.1W
POWER CONSUMPTION (VIEWFINDER): -
POWER REQUIREMENTS: 6.8V/7.3V (battery pack), 8.4V (AC Adaptor)

CHARGE ON CAMCORDER(CHARGING TIME WITH SUPPLIED BATTERY): Yes (approx. 3h 25min)
USB CHARGING: DC 5V 1500mA
USB POWER SUPPLY: -

Size & Weight

DIMENSIONS (W X H X D) (INCLUDING SUPPLIED BATTERY): Approx. 73mm x 80.5mm x 142.5mm (Approx. 73mm x 80.5mm x 173mm (NP-FV70A) (including supplied battery)), Approx. 2 7/8inch x 3 1/4inch x 5 5/8inch (Approx. 2 7/8inch x 3 1/4inch x 6 7/8inch (NP-FV70A) (including supplied battery))
WEIGHT (MAIN UNIT ONLY): Approx. 510g, Approx. 1lb 2.0oz

WEIGHT (INCLUDING SUPPLIED BATTERY): Approx. 560g (NP-FV50A), Approx. 600g (NP-FV70A) (supplied battery), Approx. 660g (NP-FV100A), Approx. 1lb 3.8oz (NP-FV50A), Approx. 1lb 5.2oz (NP-FV70A) (supplied battery), Approx. 1lb 7.3oz (NP-FV100A)
