Specification :
The HC-X2 pro camcorder offers 20x optical zoom, 24.5mm wide angle for both UHD and FHD, 4K high-precision AF with new face detection and higher precision, 5-Axis HYBRID O.I.S.+, and variety of recording formats. Includes built-in Wi-Fi, direct connection to Ethernet, and HLG*2 Gamma Mode and 13-stop V-Log for production of 4K HDR video content
| Sensor Resolution | Effective: 15.03 Megapixel |
| Sensor Type | 1"-Type MOS Sensor |
| Image Stabilization | Optical in Integrated Lens, 5-Axis (Video Only) Digital |
| Built-In ND Filter | Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters |
| Capture Type | Stills & Video |
| Shutter Type | Electronic Global Shutter |
| Shutter Speed | 1/8000 to 1/6 Second |
| Precise Scan Rate Control | No |
| Minimum Illumination | 0.2 Lux at 1/30 Shutter Speed |
| White Balance | 2000 to 15,000K Presets: ATW, Auto |
| Focal Length | 8.8 to 176mm (35mm Equivalent Focal Length: 24.5 to 490mm) |
| Optical Zoom Ratio | 20x |
| Max Digital Zoom | 32x ( in 1080p) 24x ( in UHD 4K) |
| Maximum Aperture | f/4.5 |
| Minimum Aperture | f/2.8 |
| Minimum Focus Distance | Not Specified by Manufacturer |
| Filter Size | 67 mm |
| Control Rings | Focus Zoom Iris |
| Focus Control | Autofocus Manual Focus |
| Internal Recording Modes | MOV 4:2:0 10-Bit UHD 4K (3840 x 2160) from 2 to 59.94 fps [100 to 200 Mb/s VBR] MOV 4:2:0 8-Bit UHD 4K (3840 x 2160) from 2 to 59.94 fps [150 to 150 Mb/s VBR] MOV 4:2:2 10-Bit UHD 4K (3840 x 2160) from 2 to 59.94 fps [150 Mb/s VBR] 1920 x 1080p from 2 to 59.94/100/119.88 fps [50 to 200 Mb/s VBR] 1920 x 1080i at 50/59.94 fps [50 Mb/s VBR] MP4 4:2:0 10-Bit UHD 4K (3840 x 2160) at 23.98/25/29.97/50/59.94 fps [72 to 100 Mb/s VBR] MP4 4:2:0 8-Bit UHD 4K (3840 x 2160) at 23.98/25/29.97 fps [72 Mb/s VBR] 1920 x 1080p at 23.98/50/59.94 fps [50 Mb/s VBR] AVCHD 4:2:0 8-Bit 1920 x 1080p at 23.98/29.97/50/59.94 fps [17 to 25 Mb/s VBR] 1920 x 1080i at 50/59.94 fps [17 Mb/s VBR] 1280 x 720 at 50/59.94 fps [8 Mb/s VBR] |
| Fast-/Slow-Motion Support | Yes |
| Broadcast Output | NTSC/PAL |
| Built-In Microphone Type | Stereo |
| Audio Recording | AVCHD: 2-Channel 16-Bit 48 kHz MP4: 2-Channel 16-Bit 48 kHz AAC Audio MOV: 2-Channel 24-Bit 48 kHz |
| IP Streaming | H.264, MP4, RTMP, RTMPS, RTP, RTSP 320 x 180 to 1920 x 1080 at 24p, 30p, 50p, 59.94p, 60p (0.5 to 24.00 Mb/s) |
| Image Sizes | 16:9 DCF / EXIF / JPEG 3840 x 2160 1920 x 1080 1280 x 720 |
| Aspect Ratio | 16:9 |
| Image File Format | JPEG |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-I) |
| Video I/O | 1 x 1/8" / 3.5 mm TRRS A/V (Composite) Output 1 x HDMI Output 1 x BNC (3G-SDI) Output |
| Audio I/O | 2 x XLR 3-Pin Microphone (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1 x Barrel (11.4 to 12.6 VDC) Input |
| Other I/O | 1 x 2.5 mm Sub-Mini Input 1 x USB-C Input 1 x BNC (Timecode) Input/Output |
| Wireless | Wi-Fi 4 (802.11n), Wi-Fi (802.11b/g) |
| Global Positioning (GPS, GLONASS, etc.) | None |
| Size | 3.5" |
| Resolution | 2,760,000 Dot |
| Display Type | Articulating LCD |
| Type | Built-In Electronic (OLED) |
| Size | 0.39" |
| Resolution | 1,770,000 Dot |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Automatic, Manual Focus |
| Battery Type | Panasonic AG-VBR Series |
| Accessory Mount | 1 x Cold Shoe Mount |
| Dimensions (W x H x D) | 6.8 x 7.7 x 13.5" / 17.3 x 19.5 x 34.4 cm (With Protrusions) |
| Weight | 4.50 lb / 2.04 kg (Body Only) 5.49 lb / 2.49 kg (With Battery, Grip, Viewfinder) |
| Package Weight | 8.7 lb |
| Box Dimensions (LxWxH) | 18.3 x 13.4 x 10.7" |
