MOZA Moin Pocket - Handheld Gimbal Stabilizer with 2.45-inch HD Touch Rotary Screen 4K/60 fps Camera

Size: 129*37.8*32 Net weight of the body: 176g Function: Three-axis anti-shake Specification parameters.

Structure rotation range. Pan: -250 ° ~ +70 ° Pitch: -120 ° ~ 98 ° Cross-roll: ±90° .

Controllable rotation range. Pan: -230° to +50° Pitch: -95° to 50° Traverse: ±45°.

Anti-shake correction

With ultra-high control frequency and precision to quickly respond to the user's intention to shoot, insight into the extremely small changes, even the sharp jitter brought about by intense movement, can be corrected in a split second to keep the picture stable, every frame is fine and smooth.


Time-lapse photography Support static time-lapse, motion time-lapse and track time-lapse three creative time-lapse shooting mode, easily capture the traces of the passage of time.	High-speed continuous shooting In continuous shooting mode, you can achieve a one-touch continuous shooting 9 photos, so you do not miss the key moments.	Slow motion The camera automatically recognizes the incoming face, and after selecting the tracking target, the camera will chase the shot without delay.


Panoramic shots The Gimbal automatically rotates to complete the panoramic shot, framing a more open and huge landscape.	Slow motion 8x slow speed, magnifying the beauty of the movement, every moment of detail is not spared.	60 seconds ultra-long exposure Has a long exposure of up to 60 seconds and offers a superb night mode.

Connection and battery

Data interface: Type-C
Type: Li-ion battery
Battery capacity: 930mAh
Energy: 7.14Wh
Voltage: 7.68V
Operating ambient temperature: 0? - 40?
Endurance: 145min (1080/30fps)
Charging time: 88min: 5V/2A charging power

Mode images and screens

Video mode: normal recording; slow motion; MOZA-color
Video maximum bit stream: 100Mbps
File system support: exFAT (FAT64)
Image format: JPEG/JPEG+DNG
Video format: mp4 (MPEG-4AVC/H.264)
Recommended memory card capacity: 16~256G
Audio format: 48KHZ, AAC
Screen?2.45 inches : 480*272 reversible screen
IPS LCD: flip angle: up and down flip -90 ° ~ +60 ° 90 ° open and close

Specification parameters

Maximum controlled rotation speed: 120°/S
Jitter suppression: ±0.005°
Lens: FOV 120° F2.2 , 35mm equivalent focal length: 14mm
IOS range: Photo and video: 100~3200, step 1EV
Shutter speed: 8S~1/8000S, electronic shutter
Photo maximum resolution: 4000X3000, 12MP
Video resolution: up to support 4K: 3840 * 2160 60/50/48/30/25/24P

Camera Dimensions
Dimensions
129×37.8×32mm
Camera Weight
Weight
176g
Camera
Structure Rotation Range
Pan: -250°~+70°
Tilt: -120°~98°
Roll: ±90°
Controllable Rotation Range
Pan: -230° to +50°
Tilt: -95° to 50°
Roll: ±45°
Max Controllable Speed
120°/S
Angular Vibration Range
±0.005°
Lens
FOV:120° F2.2
Equivalent Focal Length?14mm
ISO Range
Photo: 100~3200
Video: 100?3200
Shutter Speed
60S~1/8000S
Maximum Photograph Resolution
4000X3000?12MP
Video Resolution
4K: 3840X2160 @ 60/50/48/30/25/24P
4K(4:3): 3840X2880 @ /48/30/25/24
3.2K: 3200x2400 @ 30/25/24P
FHD: 1920X1080 @ 200/120/100/60/50/48/30/24P
HD: 1280X720 240/200/120/100P
2.7K: 2704X1520 60/50/48/30/25/24P
2.7K(4:3): 2704X1520 60/50/48/30/25/24P
Timelapse
Timelapse/Motionlapse
Resolution?4K(4:3)/4K/3.2K/2.7K/2.7K?4:3)/1080P
Duration: 1min/2min/3min/4min/5min
Slow Motion
720: 4X?120fps);8X(240fps)
1080P: 4X(120fps); 6X(200fps)
Photograph Mode
Single Shot, Panorama, Staticlapse, Motionlapse, Hyperlapse
Record Mode
Record?Slow Motion?MOZA-color
Max Video Bitrate
100Mbps
Supported File Formats
FAT32?≤32 GB?/exFAT (≥64 GB)
Photo Format
JPG/JPG+DNG
Video Format
mp4?MPEG-4AVC/H.264?
Supported SD Card
MicroSD Max 256G
Storage
Max 256G
Audio Output
48KHZ, AAC
Display Screen
2.45 Inches, Reversible Screen
480 x 272 IPS LCD
Reversible Angle
First Joint 0?90°
Second Joint 0?120°
Communication Interface
Wi-Fi Operating Frequency
FCC/CE/SRRC: 2.400-2.4835 GHz,
MIC:2.400-2.4835 GHz
Wi-Fi Protocol
802.11a/b/g/n/ac
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Protocol
BLE 4.2
Battery
Type
Lithium battery
Capacity
950mAh
Energy
7.14Wh
Voltage
7.68V
Operating Temperature
0? to 40?
Operating Time
145mins (Tested by Single Shot with 1080/30fps)
Charging Time
90mins (Tested by 10W Charging power)
