Feelworld LivePro L1 Multi Format Video Mixer Switcher

Rp 5.199.000 Warranty: Garansi Resmi 1 Tahun

Specification :

  • 4 x HDMI Inputs, 1 x HDMI Output
  • LAN/USB Live Streaming, PC/App Control
  • Manual T-Bar, Function Buttons/Knobs
  • 3.5mm Audio Input and Output
  • Program Output and Multiview Preview
  • Picture-in-Picture, 14 Transitions
  • 2" TFT LED Screen, PTZ/DSK Options
  • Included :
  • 1x FeelWorld LIVEPRO L1
  • 1x AC Adapter
  • 1x USB Cable
  • 1x Manual Book
  • 1x Warranty Card




Ingin cicilan 0% ? Silahkan klik :

lazada.co.id tokopedia.com blibli.com shoope.co.id bukalapak.com jd.id


Disclaimer : Pabrik dapat sewaktu-waktu mengubah kelengkapan ini, dan mungkin saja menyebabkan perbedaan antara yg tercantum di atas dengan content yg Anda terima sewaktu Anda membelinya

Switch live HDMI sources and output via USB for live streaming with this LIVEPRO L1 Multicamera Video Switcher with 4 x HDMI Inputs & USB Streaming from FeelWorld. The video switcher is a portable solution for HD video production that accommodates up to four HDMI inputs. You can control the switcher manually by using the built-in controls or connect it to a computer running optional software for additional control options. Select your working resolution and switch between your four input sources. Built into the switcher is an audio mixer that can embed audio signals from the 3.5mm analog audio input with the HDMI video signals.

There are USB and RJ45 LAN outputs that allow you to live stream via a computer to the internet or a broadcast, and you can also utilize a smartphone for control using an app. The HDMI output provides PGM (program) output with up to six sources. The built-in 2" TFT LCD allows you to view up to four PVW (preview) sources from your HDMI ports. It also supports Picture-in-Picture (PiP) mode, as well as DSK and PTZ control with optional software.

The integrated T-fader allows you to perform 14 different transition effects and manually control the speed of transitions. The unit features a program and multiview preview output, as well as an analog audio input and output.

Video switcher with four HDMI inputs and one HDMI output
Up to 1080p60 video input and output support
2" TFT display with live preview, 6-picture PVW (preview) and PGM (program) output over HDMI
Auto cut and 14 manual transitions supported with center T-bar
UVC-compliant USB video output for live streaming
Embedded audio or via external source via 3.5mm analog audio input
3.5mm analog audio output jack
Control using manual controls and buttons or via a PC or smartphone app
PiP (Picture-in-Picture) support
Optional DSK and PTZ camera control
Processing
Switching TypePushbutton, Software, T-Bar
Processing Resolution1080p at 60
Input
Number of Video Input Sources4
Video Input Connectors4 x HDMI Female
Input Video FormatHDMI
1080p: 23.98/24/25/30/50/60 fps
1080i: 50/60 fps
720p: 50/60 fps
FWXGA (1366 x 768): 60 fps
SXVGA (1280 x 1024): 60 fps
UXGA (1600 x 1200): 60 fps
WUXGA+ (1680 x 1050): 60 fps
WXGA (1280 x 800): 60 fps
WXGA+ (1440 x 900): 60 fps
XGA (1024 x 768): 60 fps
Audio Input Connectors1 x 1/8" / 3.5 mm TRS Analog Female
Embedded Audio InputHDMI
Output
Video Output Channels1
Video Output Connectors1 x HDMI Female (Program)
1 x RJ45 Female
Output Video FormatHDMI
1080p: 60 fps
720p: 60 fps
FWXGA (1366 x 768): 60 fps
WUXGA+ (1680 x 1050): 60 fps
WXGA+ (1440 x 900): 60 fps
SXGA (1280 x 1024): 60 fps
WXGA (1280 x 800): 60 fps
XGA (1024 x 768): 60 fps
Audio Output Connectors1 x 1/8" / 3.5 mm TRS Analog Female
Multiview Output6-Way Multiview
Monitor Output1 x HDMI
Connectivity
Other I/O1 x USB Type-A Output
HDCP SupportNone
Display
Display Size2"
Power
Power Connector1 x Barrel (12 VDC at 1.5 A) Input
Power ConsumptionDevice: 18 W
Environmental
Operating Temperature-22 to 122°F / -30 to 50°C
Operating Humidity10 to 85%
General
Dimensions7.3 x 4.3 x 1.5" / 18.5 x 11 x 3.9 cm
Weight22.9 oz / 648 g
