Saramonic Blink 500 B6 TX+TX+RXUC Wireless Lavalier Microphone for Android Type-C

Contents:

1× Blink500 RXUC Receiver with USB-C Connector

2× Blink500 TX Transmitters with Built-In Microphone and Clip

2× SR-M1 Omnidirectional Lavalier Microphones

2× Alligator-Style Lavalier Microphone Clips

2× Foam Lavalier Windscreens

2× 1’ (30.5 cm) Gold-Plated USB-C to USB-A Charging Cables

1× Pairing Pin

1× Warranty Card

1× User Manual

Disclaimer : Pabrik dapat sewaktu-waktu mengubah kelengkapan ini, dan mungkin saja menyebabkan perbedaan antara yg tercantum di atas dengan content yg Anda terima sewaktu Anda membelinya.

Simplify and expedite your entry into wireless audio with the Saramonic Blink 500 B6, an ultracompact and extraordinarily easy-to-use true wireless microphone system offering a cost-effective, all-inclusive solution for recording two subjects to Android devices and Mac/Windows computers equipped with USB Type-C ports.

The Blink 500 B6 delivers considerably improved sound quality compared to the built-in mics on cameras and mobile devices while functioning as an ultracompact digital system that provides immediate out-of-the-box operability for anyone, making it ideal for video, podcast, and mobile journalism applications. Once it's plugged in and powered on, it's set and ready so your focus can stay on your content.

Equally straightforward and small, the Blink 500 B6 gives you everything necessary for recording crisp, clear speech in any location. You get two clip-on transmitters—each with a built-in microphone and a clip-on omni lavalier mic, a dual-channel receiver that plugs directly into your device, and the requisite charging cables for the transmitters. Whether you're a run-and-gun videographer, a YouTube content creator, or an avid vlogger, the Blink 500 B6 can get your wireless audio going in no time.

Unpacking the Blink 500 B6

Use each ultracompact clip-on transmitter as a true wireless microphone with its built-in mic element, or as a bodypack transmitter with its supplied clip-on lavalier microphone.
The ultracompact dual-channel receiver plugs directly into your device's USB Type-C port, letting it work seamlessly with Android mobile devices and Mac/Windows computers equipped with USB Type-C ports—no batteries, cables, or clips required.
Simply plug in the receiver and power on the transmitters to access reliable wireless audio functionality in an instant.

Connect, Power, and Go

With the receiver and transmitters paired at the factory, the Blink 500 system is comfortably easy to use for anyone, anywhere. Videographers, vloggers, YouTubers, and mobile journalists will benefit from the Blink 500's power-and-go operating style.
Advanced technology invisibly handles the complicated tasks such as switching channels to avoid dropouts, leaving you with a streamlined and simple system that requires no menu diving or tedious manual configuration.

Quality Sound

Blink 500 systems utilize 24-bit / 48 kHz resolution—the same audio standard used worldwide by sound engineers in the film industry—to give you quality sound at a budget-friendly price point.
Compared to the built-in microphones on cameras and mobile devices, Blink 500 systems offer considerably improved fidelity and clarity with less noise.
Since your subjects may speak at very different volumes, Saramonic outfitted the Blink 500 TX with dedicated gain buttons to allow quick and effortless adjustment of the signal level. You can even turn the volume all the way down to effectively mute the transmitter.
By connecting directly to your device's USB Type-C port, the Blink 500 RXUC avoids unnecessary D/A and A/D conversion to maintain the integrity of the digital signal from your transmitter all the way to your recording device.

Perfect for 1- or 2-Person Shoots

Since the Blink 500 RXUC is a dual-channel receiver, it can simultaneously handle both Blink 500 TX wireless transmitters. If you need to expand beyond that, you can use up to 18 Blink 500 systems at once to accommodate up to 36 wireless microphones.
Each Blink 500 system can include one dual-channel receiver and up to two transmitters. Choose from camera-mount (Blink 500 RX), Lightning (Blink 500 RXDi), or USB Type-C (Blink 500 RXUC) receivers.

Built-In Microphone for True Wireless Operation

The Blink 500 TX features a built-in miniature condenser microphone with an omni pickup pattern that captures clear and natural voice tonality. Thanks to the transmitter's ultracompact housing, you can clip it to clothing, slide it into a shirt pocket, place it on a podium, or hold it in your hand.

Lavalier Microphone Included

For maximum visual discretion, use the Blink 500 TX as traditional bodypack transmitter with the supplied lavalier microphone. Just clip the omni lav mic to a collar or lapel, then plug it into the transmitter's 3.5mm input; the transmitter automatically switches to the external microphone so you don't have to bother selecting the input source.
The lavalier mic includes a foam windscreen that lessens noise caused by light wind, breaths, and air conditioning systems. For enhanced reduction of stronger wind noise, a separately available furry windshield (a.k.a. windjammer) such as the Saramonic LM-WS can be fitted to the microphone.

Stable and Simple 2.4 GHz Digital Wireless

Whereas typical analog wireless systems are susceptible to interference from TV and radio waves, the Blink 500 digital system avoids that by operating in the 2.4 GHz band, which occupies frequencies beyond those of television, radio transmissions, and UHF wireless microphone systems.
Within the 2.4 GHz spectrum, the Blink 500 boasts automatic channel hopping to mitigate noise and dropouts at a line-of-sight distance of up to 164 feet. For optimal performance, environments with limited Wi-Fi / 2.4 GHz traffic and minimal physical obstructions are recommended.

Ready for Anywhere

Don’t be concerned about licensing or selecting frequencies; the Blink 500 system uses the license-free 2.4 GHz band, so you can go anywhere in the world and have a reliable, fully functional wireless system.

Other Features

Lightweight, ultracompact housings
Slim plug-in receiver won't interfere with the operation of a gimbal
USB Type-C male connector plugs directly into your device's USB Type-C port
Works with Android devices and Mac/Windows computers equipped with USB Type-C ports
Receiver requires no battery or charging
Transmitter's intelligent LED indicators show power, audio level, low-battery level, and charging status
Transmitter's internal 5-hour battery keeps you going on long shoots or multiple run-and-gun gigs in a day
Power the transmitter or recharge its internal lithium-ion battery via a USB Type-C connection (charging cables included)
Use up to two transmitters with each receiver
Operate up to 18 systems simultaneously in the same environment

System

Wireless Transmission	Digital 2.4 GHz
Number of RF Channels	18
Included Transmitters	1 x Clip-On with Microphone
Diversity	Non-Diversity
RF Frequency Band	2400 to 2483.5 MHz
RF Bandwidth	Up to 83.5 MHz
Max Operating Range	164' / 50 m (Line of Sight) 98.4' / 30 m (with Obstruction)
Max Systems per Setup	18
Sample Rate/Resolution	48 kHz / 24-Bit
Latency	12 ms
Encryption	None
Modulation	GFSK

Receiver

Form Factor	Plug-In
Mounting Options	Plug-In
Antenna	1 x 1/4 Wave Wire, Fixed
Number of Audio Channels	2
Audio I/O	1 x 1/8" / 3.5 mm TRS Female Unbalanced Line Output
Audio Output Level	5 dB
Frequency Response	20 Hz to 16 kHz
Network I/O	None
Word Clock I/O	None
USB/Lightning Connectivity	1 x USB Type-C (Audio, Bus Power)
Power Requirements	Bus Power (USB)
Display & Indicators	1 x LED (Power, Sync)
Housing	ABS, Plastic
Operating Temperature	32 to 122°F / 0 to 50°C
Storage Temperature	-4 to 122°F / -20 to 50°C
Dimensions	3 x 0.7 x 0.4" / 7.6 x 1.7 x 1.1 cm
Weight	0.4 oz / 10 g

Transmitter

Form Factor	Clip-On with Microphone
RF Output Power	10 mW
Audio I/O	1 x 1/8" / 3.5 mm TRS Female Unbalanced Input
Plug-In Power	1 V
Pad	None
Muting	None
Audio Input Level	-42 to -30 dBV (at 0 dB Gain)
Gain Range	+11 to +25 dB (7 dB Steps)
Signal Processing	None
Frequency Response	20 Hz to 16 kHz
Sync Method	IR
Antenna	1 x 1/4 Wave Wire, Fixed
Power Requirements	Battery or Bus Power (USB)
Battery Type	1 x Built-In Rechargeable (Included, Not Replaceable)
Internal Battery Capacity	400 mAh
Battery Charging Time	1.5 to 2.5 Hours
Approx. Battery Life	5 Hours
USB/Lightning Connectivity	1 x USB Type-C (Bus Power, Charging)
Display & Indicators	4 x LED (Audio Level, Power) 1 x LED (Battery Status) 1 x LED (Recharging)
Housing	ABS, Plastic
Operating Temperature	32 to 122°F / 0 to 50°C
Storage Temperature	-4 to 122°F / -20 to 50°C
Dimensions	2.5 x 1.7 x 0.7" / 6.3 x 4.3 x 1.7 cm
Weight	1.2 oz / 34 g

Microphone

Form Factor	Lavalier
Color	Black
Sound Field	Mono
Operating Principle	Pressure Operated
Capsule	Electret Condenser
Polar Pattern	Omnidirectional
Frequency Range	50 Hz to 18 kHz
Equivalent Noise Level	58 dB
Maximum SPL	110 dB SPL
Sensitivity	-30 dB
Output Connectors	1 x 1/8" / 3.5 mm TRS Male Unbalanced
Cable Length	4' / 1.22 m
Operating Voltage	1 V

Microphone 2

Form Factor	Integrated
Sound Field	Mono
Operating Principle	Pressure Operated
Capsule	Electret Condenser
Polar Pattern	Omnidirectional
Frequency Range	50 Hz to 18 kHz
Equivalent Noise Level	58 dB
Maximum SPL	120 dB SPL
Sensitivity	-42 dB
