| Product Name | Feiyu SCORP-Mini 3-Axis Handheld Gimbal for Camera |
| Battery Capacity | 2500mAh, built-in battery cannot be removed, charge it via the USB-C port which below the multifunction knob,support all the normal charger and quick charger which charging power≤18W
|
| Operating Voltage | 6.8V-8.4V |
| Theoretical Battery Life | 13h |
| Charging Time | About 1.6h (Using 18W fast charger) |
| Materials In Main Body | Synthetic macromolecular resin, aluminum alloy |
| Weight | About 787g/1.735 lb (including quick release plate, not included other accessories and camera) |
| Payload | About 1200g/2.65 lb (well balanced) |
| Water-Proof Grade | Not Water-proof |
| Dimensions | 228*179*272mm(Gimbal balancing position)
227*114*288mm(Gimbal folded position)
|
| Compatible Cameras/Smartphones | Mirrorless camera and pocket camera (Sony, Canon, Nikon, Panasonic,etc. Check Camera Compatibility Lists for more details), action camera like GoPro, and smartphone (Width: 52mm~82mm, thickness: ?8.9mm)
|
| Operating Temperature | -10~45?
|
| Rotatable Range | Tilt: 280°(With limitation)
Roll: 290°(With limitation)
Pan: 360°(Unlimited)
|
| Controllable Range | Tilt: +170°~-45°
Roll: +40°~-40°
Pan: 360°(Unlimited)
|
| Quick Release Plate | Quick release plate (75.19x38x17mm) is compatible with ARCA quick release system.
Can be removed from the gimbal together with the camera, and fast switch between popular quick release systems without re-assembling the camera.
|
| Follow Mode |
?PF: Pan follow, only the pan axis follows the movement of user's hand
?PTF: Pan and tilt follow, where both the pan and tilt axes follow the movement of user's hand, but roll axis does not
?FPV: Pan, tilt and roll follow, where all 3 axes follow the movement of user's hand
?Lock: All 3 axes do not follow the movement of user's hand, gimbal keeps the direction of the camera fixed
?FFW: flash follow, where all 3 axes follow the movement of user's hand in high follow speed
|
| APP | When mounting mirrorless camera or pocket camera on gimbal for shooting, please use “Feiyu SCORP” App.
When mounting action camera on gimbal for shooting, users can only remote control the gimbal via “Feiyu SCORP” App( Action camera control does not support yet).
When mounting smartphone on gimbal for shooting, please use “Feiyu ON” App.
Both Feiyu ON and Feiyu SCORP can update firmwares for gimbal.
|
| How To Control The Camera/Smartphone | While connecting gimbal and cameras with cable (Standard accessories for SONY, CANON, NIKON, Panasonic), users can control picture-taking/recording with shutter button and set aperture, shutter, ISO and other camera parameters (see Camera Compatibility List for more).
After connect gimbal with Feiyu ON App via Bluetooth, the gimbal can directly control Feiyu ON to shoot (If the shutter of original camera and third party camera App can be controlled by volume button,then SCORP-Mini can control it too).
Only provides stabilization for action cameras. Button controls are not supported, please wait for firmware update.
|
| Motor Power Auto Tune | Auto Tune motor power is available to the App or Touch Screen. Gimbal auto tune the motor power according to the camera you install.
Auto Tune operation: Enter the motor power setting through touch screen, and tap Auto Tune, then put gimbal on the table until the display prompt calibration complete.
Gimbal will vibrate slightly while Auto Tune to weigh the camera, it’s a normal phenomenon.
|
| Extended Ports | At the bottom of the handle: 1/4 inch thread hole*1, which can mount Tripod;
Below the multifunction knob: Type-C charging port*1;
In front of fixed plate: Type-C extension port*1 to connect focus motor and other accessories;
Type-C camera control port*1;
1/4 inch thread hole*1, for installation of focus motor support rod;
In front of quick release plate: 1/4 inch thread hole*1, for installation of lens holder;
|
| Standard Accessories | Feiyu SCORP*1
Data cable USB 2.0 to Type-C*1
Shutter cable Type-C to Micro (A03)*1
Shutter cable Type-C to Type-C (C02)*1
Shutter cable Type-C to TRS2.5 (T02)*1
Sony shutter cable Type-C to Multi*1
Panasonic shutter cable (DC2.5mm) Type-C to 2.5mm*1
Tripod*1
Quick release plate*1
Fixed plate slider*1
Smartphone holder*1
Lens holder*1
Lens holder screw*1
Focus motor support rod*1
Fixed screw for support rod*1
Long thumb screw*1
GoPro adapter*1
Camera fixed screw*1 |
