Peripheral

• Accessory Port

• 1/4"-20 Mounting Hole
  RSS Camera Control Port (USB-C)
  NATO Expansion Port

• Battery

• Model: HB7-2450mAh-7.2V
  Type: 18650 Li-ion 2S
  Capacity: 2450 mAh
  Energy: 17.64 Wh
  Operating Time: 10 hours [1]
  Charging Specification: 5 V/2 A
  Charging Time: Approx. 2.5 hours [2]
  Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

• Connections

• Bluetooth 5.1
  USB-C Charging Port

• Ronin App Requirements

• iOS 11.0 or above
  Android 7.0 or above

• Languages Supported by the Touchscreen

• English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance

• Tested Payload

• 0.4-2 kg (0.8-4.4 lbs)

• Maximum Controlled Rotation Speed

• Pan: 360°/s
  Tilt: 360°/s
  Roll: 360°/s

• Mechanical Range

• Pan Axis: 360° continuous rotation
  Roll Axis: -95° to +240°
  Tilt Axis: -10° to +210°

Mechanical & Electrical Properties

• Operating Frequency

• 2.4000-2.4835 GHz

• Bluetooth Transmitter Power

• <4 dBm

• Operating Temperature

• -10° to 45° C (14° to 113° F)

• Weight

• Gimbal: 795 g (1.75 lbs) in portrait mode and 850 g (1.8 lbs) in horizontal shooting mode (both including the Quick-Release Plate and excluding the Extended Grip/Tripod)
  Extended Grip/Tripod: Approx. 128 g (0.2 lbs)

• Dimensions

• Folded: 323×195×98 mm (L×W×H, height excludes the Extended Grip/Tripod)
  Unfolded: 180×159×296 mm (L×W×H, excluding camera and the Extended Grip/Tripod)

Other

• Footnotes

• 1. Measured with the equipment in a level and stationary state and the gimbal balanced. When the gimbal is in motion, the operating time will be reduced.
  2. Tested in a 25° C (77° F) environment while using a 10W charger.
