Specification :
Panasonic's HC-MDH3 AVCHD Shoulder Mount Camcorder with LCD Touchscreen & LED Light is at home shooting corporate, event, or indie projects. It features a 1/3.1" BSI MOS sensor for improved low-light performance, and incorporates a 20x zoom lens with five-axis hybrid image stabilization. The lens also features a single manual ring that you select to control focus, zoom, iris, white balance, or shutter speed. Built into the top handle is an LED light for illuminating your subject.
Two viewfinders provide you with a choice of operating the camera with either a traditional tilt-up color EVF, or a pullout LCD high-resolution touchscreen. The LCD touchscreen is positioned above the lens for a more natural viewing experience when shooting handheld. The camera records in MP4, MOV, or AVCHD codecs, and features dual SDXC media card slots, allowing you to use relay or simultaneous recording. The lens incorporates an illuminating ring that indicates when the camera is in standby or record mode. You can also deactivate the indicator if you wish.
| Sensor | |
|---|---|
| Sensor | 1/3.1"-type BSI MOS Sensor |
| Effective Pixels | 6.03 MP (16:9) |
| Camera | |
|---|---|
| Illumination | Standard: 1400 lux Minimum: 1.2 lux (Super Gain 36 dB, shutter 1/25) |
| Focus | Auto / Manual |
| Shutter Speed | 50p/i: 1/6 - 1/8000 Super Slow: 1/100 - 1/8000 |
| Optics | |
|---|---|
| Focal Length | 4.08 - 81.6mm |
| 35mm Equivalent Focal Length | 29.5 to 612mm (16:9) |
| Maximum Aperture | f/1.8 - f/3.6 |
| Zoom | Optical: 20x Intelligent: 40x (in HD) Digital: 2x, 5x, 10x |
| Iris | Auto/Manual |
| Filter Size | 49 mm |
| Recording | |
|---|---|
| System | NTSC |
| Formats | MP4 1920 x 1080 59.94p 50M: Average 50 Mb/s (VBR), LPCM 1920 x 1080 59.94i 50M: Average 50 Mb/s (VBR), LPCM 1920 x 1080 29.97p 50M: Average 50 Mb/s (VBR), LPCM 1920 x 1080 23.98p 50M: Average 50 Mb/s (VBR), LPCM MOV 1920 x 1080 59.94p 50M: Average 50 Mb/s (VBR), LPCM 1920 x 1080 59.94i 50M: Average 50 Mb/s (VBR), LPCM 1920 x 1080 29.97p 50M: Average 50 Mb/s (VBR), LPCM 1920 x 1080 23.98p 50M: Average 50 Mb/s (VBR), LPCM AVCHD PS: 1920 x 1080 59.94p, average 25 Mb/s (VBR) PH: 1920 x 1080 59.94i, average 21 Mb/s (VBR)) PH: 1920 x 1080 23.98p, average 21 Mb/s (VBR) HA: 1920 x 1080 59.94i, average 17 Mb/s (VBR) HE: 1440 x 1080 59.94i, average 5 Mb/s (VBR) PM: 1280 x 720 59.94p, average 8 Mb/s (VBR) SA: 720 x 576 59.94i (side crop/squeeze), average 9 Mb/s (VBR) |
| Card Slots | Dual SDHC/SDXC |
| Media Capacity | 32 GB to 2 TB |
| Still Image Resolution | JPEG 1920 x 1080: 2.1 MP 640 x 480: 0.3 MP 640 x 360: 0.2 MP |
| Audio Format | MOV: LPCM MP4: LPCM AVCHD: Dolby (2-channel) |
| Input/Output Connectors | |
|---|---|
| Inputs | 1 x 1/8" / 3.5 mm mini jack (zoom) 1 x 2.5 mm super mini jack (focus/iris) |
| Outputs | 1 x A/V 1 x HDMI type A 1 x USB 3.0 Type-A (host) 1 x USB 3.0 Micro-B |
| Headphone Jack | 1/8" / 3.5 mm stereo mini |
| Built-in Mic | Yes |
| Built-in Speaker | Yes |
| Accessory Shoe | 1 x Cold shoe |
| Tripod Mount | 1/4"-20 |
| Display | |
|---|---|
| LCD Screen | Type: Touchscreen LCD Size: 3.0" / 7.6 cm Resolution: 460,800 dots |
| EVF | Size: 0.24" / 0.61 cm Resolution: 1.55 MP |
| LEDs | |
|---|---|
| Photometric Data | Clear: 300 lux @ 3.28' / 1 m With Included Diffusion: 70 lux @ 3.28' / 1 m |
| Beam Angle | 30° (approximately) |
| Color Temperature | 5000K (approximately) |
| General | |
|---|---|
| Battery | Rechargeable lithium-Ion battery, 7.2 VDC |
| Charging Method | AC adapter |
| Power Consumption | Recording: 9.2 W Charging: 27. W |
| Dimensions | 8.07 x 8.54 x 19.4" / 20.50 x 21.69 x 49.28 cm |
| Weight | 5.1 lb / 2.3 kg (without battery or SD card) |
| Packaging Info | |
|---|---|
| Package Weight | 9.05 lb |
| Box Dimensions (LxWxH) | 22.3 x 13.2 x 12.3" |
