Specification :
Sporting a classic design and sleek form factor, the silver OM-D E-M10 Mark II from Olympus is a mirrorless Micro Four Thirds digital camera featuring refined stills and movie recording capabilities to suit working in a variety of day-to-day environments. A high-resolution 16.1MP 4/3 Live MOS sensor pairs with the TruePic VII image processor to facilitate up to 8.5 fps shooting and full HD 1080p/60 movie recording, with a top sensitivity of ISO 25600. In-camera 5-axis image stabilization compensates for up to 4 stops of camera shake to benefit working in difficult lighting conditions and a FAST AF system employs 81 contrast-detection areas for quick, accurate performance with dedicated subject tracking modes. The retro-themed body incorporates a range of assignable function buttons and dials, as well as a 2.36m-dot OLED electronic viewfinder and 3.0" 1.04m-dot tilting touchscreen LCD for clear image monitoring and playback. Besides the handsome appeal of the E-M10 Mark II's design, its main assets lie in its versatility of shooting functions and performance to benefit photographers and videographers alike.
Benefited by the range of imaging capabilities, the E-M10 Mark II also incorporates a variety of shooting modes to suit working in various situations. A Silent Mode utilizes an electronic shutter for perfectly quiet picture-taking, with shutter speeds up to 1/16,000 sec. available. Live Bulb and Live Time modes are well-suited to creative long exposure photography and a dedicated Live Composite mode lets you watch a long exposure gradually build up during the course of the shot. Built-in Wi-Fi allows you to pair the camera with your smartphone or tablet for wireless sharing and remote camera control, and an interval shooting mode can be used to produce in-camera 4K time lapse movies.
Included with the camera is the versatile M.ZUIKO Digital ED 14-42mm f/3.5-5.6 EZ, which covers a wide-angle to portrait-length 28-84mm equivalent focal length range. A series of aspherical, ED, and high refractive index elements work to control aberrations and distortions for notable image sharpness and clarity, and the lens' sleek 0.9"-thick profile is well-matched to the compact form factor of the E-M10 Mark II.
| Imaging | |
|---|---|
| Lens Mount | Micro Four Thirds |
| Camera Format | Micro Four Thirds (2x Crop Factor) |
| Pixels | Actual: 17.2 Megapixel Effective: 16.1 Megapixel |
| Max Resolution | 4608 x 3456 |
| Aspect Ratio | 1:1, 3:2, 4:3, 16:9 |
| Sensor Type / Size | MOS, 17.3 x 13 mm |
| File Formats | Still Images: JPEG, MPO, RAW Movies: AVI, MOV, MPEG-4 AVC/H.264 Audio: Linear PCM (Stereo) |
| Bit Depth | 12-Bit |
| Dust Reduction System | Yes |
| Memory Card Type | SDHC SDXC |
| Image Stabilization | Sensor-Shift, 5-Way |
| AV Recording | |
|---|---|
| Video Recording | Yes, NTSC/PAL |
| Aspect Ratio | 4:3, 16:9 |
| Video Clip Length | Up to 29 Min |
| Audio Recording | Built-In Mic: With Video (Stereo) |
| Focus Control | |
|---|---|
| Focus Type | Autofocus |
| Focus Mode | Continuous-Servo AF (C), Manual Focus (M), Single-servo AF (S) |
| Autofocus Points | Contrast Detection: 81 |
| Viewfinder/Display | |
|---|---|
| Viewfinder Type | Electronic |
| Viewfinder Eye Point | 19.2 mm |
| Viewfinder Coverage | 100% |
| Viewfinder Magnification | Approx. 1.08x |
| Diopter Adjustment | -4 to +2 m |
| Display Screen | 3" Rear Touchscreen Tilting LCD |
| Exposure Control | |
|---|---|
| ISO Sensitivity | Auto, 200-25600 (Extended Mode: Auto, 100-25600) |
| Shutter | Type: Electronic & Mechanical Speed: 60 Second Type: Electronic & Mechanical Speed: .5 - 1 Minute in Bulb Mode Type: Electronic Speed: 60 Second |
| Remote Control | RM-UC1 (Optional) |
| Metering Method | Center-Weighted Average Metering, Multi-Zone Metering, Spot Metering, Highlight Weighted |
| Exposure Modes | Modes: Underwater, Time, Program Shift, Programmed Auto, Bulb, Manual, Aperture Priority, Scene Selection, Art Filter, Shutter Priority, Intelligent Auto Metering Range: EV -2.0 - EV 20.0 Compensation: -5 EV to +5 EV (in 1/3, 1/2 or 1 EV Steps) |
| White Balance Modes | Auto, Custom |
| Buffer/Continuous Shooting | Up to 8.5 fps at 16.1 MP for up to 36 Frames in Raw Format Up to 4 fps at 16.1 MP |
| Flash | |
|---|---|
| Flash Modes | Red-Eye Reduction Fill-In Slow Sync/Red-Eye Reduction Off Slow Sync Auto Second-Curtain Sync Manual |
| Built-in Flash | Yes |
| Guide No. | 19.03' (5.8 m) ISO100 |
| Max Sync Speed | 1 / 250 Second |
| Flash Compensation | -3 EV to +3 EV (in 1/3, 1/2 or 1 EV steps) |
| Dedicated Flash System | TTL Remote Firing Groups: 4 Channels: 4 |
| External Flash Connection | Hot Shoe |
| Performance | |
|---|---|
| Self Timer | 12 Seconds, 2 Seconds Custom: 1 - 30 Seconds at 0.5-, 1.0-, 2.0-, 3.0Second Intervals Number of Shots: 1 - 10 |
| Interval Recording | Yes |
| Connectivity | HDMI D (Micro), USB 2.0 |
| Wi-Fi Capable | Yes |
| Power | |
|---|---|
| Battery | 1 x BLS-50 Rechargeable Lithium-Ion Battery Pack, 7.2 VDC, 1175 mAh |
| Operating/Storage Temperature | Operating 32 to 104°F (0 to 40°C) Humidity: 30 - 90% |
| Physical | |
|---|---|
| Dimensions (W x H x D) | 4.7 x 3.3 x 1.8" / 119.5 x 83.1 x 46.7 mm |
| Weight | 13.76 oz / 390 g with battery and memory card |
| Kit Lens | |
|---|---|
| Focal Length | 14 - 42mm Comparable 35mm Focal Length: 28 - 84 mm |
| Aperture | Maximum: f/3.5 - 5.6 Minimum: f/22 |
| Angle of View | 79° - 29° |
| Minimum Focus Distance | 7.9" / 20.07 cm |
| Magnification | 0.23x |
| Maximum Reproduction Ratio | 1:4.35 |
| Optical Design | 8 Elements in 7 Groups |
| Diaphragm Blades | 5, Rounded |
| Autofocus | Yes |
| Filter Thread | Front: 37 mm |
| Dimensions (DxL) | Approx. 2.4 x 0.9" / 60.96 x 22.86 mm |
| Weight | 3.2 oz / 91 g |
| Packaging Info | |
|---|---|
| Package Weight | 2.95 lb |
| Box Dimensions (LxWxH) | 9.4 x 9.1 x 3.9" |
