Fujifilm X-H2 Accesories Package Mirrorless Digital Camera

Included :
1x Camera
1x Vertical Battery Grip VG-XH
1x Cooling Fan XH2
1x NP-W235
1x AC power adapter
1x Plug adapter
1x USB cable
1x Shoulder strap
1x Body cap
1x Hot shoe cover
1x File transmitter/vertical battery grip connector cover
1x Memory card slot cover
1x Sync terminal cover
1x Cooling fan connector cover
1x Cable protector
1x Owner's manual

Pushing the boundaries of APS-C imaging, the FUJIFILM X-H2 is a high-resolution mirrorless crop-sensor camera featuring a groundbreaking 40MP BSI sensor and an arsenal of cutting-edge features packed into a small and durable X-series body. Standing atop the X-System lineup, this high performing camera inherits many of the GFX system's advances in digital capture technology to provide image quality, detail, and color rendition never before seen in a crop-sensor camera, while retaining its characteristic compact form factor and sleek design that has garnered the X-System a loyal following worldwide.

Backside-Illuminated Sensor and 64-Bit Processing

X-Trans 5 BSI Sensor

Ideal for architectural, travel, and landscape photographers, the X-H2 sports a backside-illuminated, APS-C-format 40MP X-Trans 5 HR sensor, which ups the resolution and improves low-light performance compared to previous generations. First, as an X-Trans sensor, it uses the unique color filter array that inherently minimizes moiré and contributes to more natural color rendering; next, the BSI design helps reduce noise and improve tonality and clarity; and, finally, the design greatly reduces rolling shutter and other motion distortion to better suit high-speed video and photo applications. The remarkable resolution allows for 2x digital zoom and has up to 13 stops of dynamic range.

X-Processor 5

Partner to the newly designed sensor is a fresh engine—the X-Processor 5—which uses 64-bit processing to realize 3x faster speeds for both video and photo tasks compared to the X-T4. On the video side, this enables recording at bit rates of up to 720 mb/s.

On the stills end, this quick processing means faster shooting to suit photographing moving subjects. When working with an electronic shutter, shooting at up to 20 fps is possible, with a buffer of 202 consecutive uncompressed raw frames. With the mechanical shutter, shooting speeds of up to 15 fps are possible, along with the ability to shoot upwards of 1000 raw frames in a single burst.

Benefitting both video and stills applications, this processing also benefits the sophisticated and AI-backed autofocus system, helps achieve a 14-stop dynamic range, and enables an enhanced sensitivity range from ISO 160-12800, a first for the X-System.

Powerful Video Capabilities

4K 120p and 8K 30p Internal Recording

Despite its focus on photography, the X-H2 has an impressive video system capable of 4:2:2 10-bit internal recording in 8K at 30fps and in both DCI/UHD 4K at up to 60 fps and Full HD at up to 240p. A variety of codecs are supported as well, including H.265 and three tiers of ProRes: the high bitrate 422 HQ, the standard 422, and the more compressed 422 LT. Also, continuous recording times up to 160 minutes are possible at all frame rates and resolutions and can be extended to 240 minutes with the external clip-on fan.

External Raw Recording

Using the full-size HDMI port, 12-bit raw video recording is possible when paired with a compatible external recorder. Both ProRes RAW and Blackmagic RAW recording is possible, along with the ability to work with F-Log or F-Log 2 profiles, and either format supports working in resolutions up to the open-gate 8K.

Improved Autofocus and Image Stabilization

Hybrid AF with Deep Learning AI

Benefitted by the improved processing, autofocus performance is noticeably faster and more intelligent. This hybrid focusing system uses 425 phase-detection points and is now sensitive down to -7 EV for working in truly low-light conditions. Also, backed by deep learning, an AI adaptive algorithm means this focusing system is better suited to automatically detect and track a variety of subject types.

In-Body Image Stabilization

Built-in 5-axis sensor-shift image stabilization helps to minimize the appearance of camera shake by up to 7 stops. This system works in conjunction with most X Series lenses, including non-stabilized ones, and benefits working with slower shutter speeds and when shooting in difficult lighting conditions. Additionally, digital image stabilization can also be used during video recording to further aid in steadying footage, especially when recording handheld.

Body Design

Practical and Durable Design

Large OLED electronic viewfinder features a crisp 5.76m-dot resolution and a 0.8x magnification for bright, clear, and detailed eye-level viewing.
Rear 3.0" LCD has a high 1.62m-dot resolution and a touchscreen interface for intuitive control. Also, its vari-angle design means the screen can be flipped out to the side, tilted up or down, and closed with the screen against the body for protection.
1.28" monochrome LCD screen on the top plate is a simple means for quickly reviewing shooting settings.
Dual memory card slots include one CFexpress Type B slot and one SD UHS-II slot for file-saving flexibility. The CFexpress Type B slot should be prioritized for higher bitrate video recording and fast continuous shooting, and the SD slot is a convenient alternative for backups or less speed-critical shooting.
NP-W235 battery provides approximately 720 frames per charge when working with the EVF in Economy Mode, or approximately 580 frames in Normal Mode.

Connectivity

Full-size HDMI Type A port for outputting video to an external recorder or monitor.
USB 3.2 Gen 2 Type-C port supports tethering, data transfer, and in-camera battery charging.
3.5mm headphone and external microphone ports for greater control over audio recording.
PC sync port for flash sync.
2.5mm remote port for using wired remote controllers.
Integrated Bluetooth and Wi-Fi connectivity allows for wirelessly sharing images to a mobile device or to use the device to remotely control the camera.

Film Simulation Modes

Film Simulation modes allow you to reproduce the look and feel of several of FUJIFILM's film types, including Provia, Velvia, Astia, Classic Chrome, Classic Neg., Nostalgic Neg., Pro Neg. Hi, Pro Neg. Standard, Eterna, Eterna Bleach Bypass, Acros, Monochrome, and Sepia. Additionally, Grain Effect can be adjusted as well as Color Chrome effect to fine-tune the look of imagery.

Model name		FUJIFILM X-H2
Lens Mount		FUJIFILM X mount
Image sensor		23.5mm x 15.6mm (APS-C) X-Trans CMOS 5 HR with primary color filter
Number of effective pixels		40.2 millions pixels
Sensor Cleaning System		Ultra Sonic Vibration
Image Processing Engine		X-Processor 5
Storage media		SD Card (-2GB) / SDHC Card (-32GB) / SDXC Card (-2TB) / UHS-I / UHS-II / Video Speed Class V90 / CFexpress Type B Card (-2TB) Please check Compatibilityfor more detail. Please check the list of the operation confirmed CFexpress Type B Card
File format of still image	DCF	Compliant with Design rule for Camera File system (DCF2.0)
	JPEG	Exif Ver.2.32^*1
	HEIF	4:2:2 10bit
	RAW	14bit RAW (RAF original format)
	TIFF	8bit / 16bit RGB (In-camera Raw Conversion Only)
Number of recorded pixels	?L?	?4:3? 6864 x 5152 ?3:2? 7728 x 5152 ?16:9? 7728 x 4344 ?1:1? 5152 x 5152 ?5:4? 6432x5152
	?M?	?4:3? 4864 x 3648 ?3:2? 5472 x 3648 ?16:9? 5472 x 3080 ?1:1? 3648 x 3648 ?5:4? 4560x3648
	?S?	?4:3? 3464 x 2592 ?3:2? 3888 x 2592 ?16:9? 3888 x 2184 ?1:1? 2592 x 2592 ?5:4? 3264x2592
Panorama	?L?	?vertical? 9600 x 2160 ?Horizontal? 9600 x 1440
	?M?	?vertical? 6400 x 2160 ?Horizontal? 6400 x 1440
Digital Tele-Converter		2.0x / 1.4x / OFF
Sensitivity	Still Image	Standard Output: AUTO1 / AUTO2 / AUTO3 /ISO125-12800 (1/3 step) Extended Output: ISO64 / ISO80 / ISO100 / ISO25600 / ISO51200
	Movie	Standard Output: AUTO / ISO125-12800 (1/3 step) Extended Output: ISO25600
Exposure control		TTL 256-zone metering / Multi / Spot / Average / Center Weighted
Exposure mode		P (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure)
Exposure compensation	Still	-5.0EV - +5.0EV?1/3EV step
	Movie	-2.0EV - +2.0EV 1/3EV step
Image stabilizer	Mechanism	Image sensor shift mechanism with 5-axis compensation
	Compensation Effect	7.0 stops based on CIPA standard Pitch/yaw shake only *With XF35mmF1.4 R lens mounted
	Digital Image Stabilization	Yes (movie mode only)
	IS MODE BOOST	Yes (movie mode only)
Shutter type		Focal Plane Shutter
Shutter speed	Mechanical shutter	P mode: 4sec. to 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb: up to 60min.
	Electronic shutter	P mode: 4sec. to 1/180000sec. A mode: 30sec. to 1/180000sec. S/M mode: 15min. to 1/180000sec. Bulb: 1sec. Fixed
	Electronic front curtain shutter	P mode: 4sec. to 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb: up to 60min.
	Mechanical + Electronic shutter	P mode: 4sec. to 1/180000sec. A mode: 30sec. to 1/180000sec. S/M mode: 15min. to 1/180000sec. Bulb: up to 60min. *Mechanical shutter works until 1/8000sec.
	E-front + Mechanical shutter	P mode: 4sec. to 1/8000sec. A mode: 30sec. to 1/8000sec. S/M mode: 15min. to 1/8000sec. Bulb: up to 60min. *Electronic front curtain shutter works until 1/2000sec.
	E-front + Mechanical + Electronic shutter	P mode: 4sec. to 1/180000sec. A mode: 30sec. to 1/180000sec. S/M mode: 15min. to 1/180000sec. Bulb: up to 60min. Electronic front curtain shutter works until 1/2000sec, Mechanical shutter works until 1/8000sec. The Electronic Shutter may not be suitable for fast-moving objects or handheld shooting. Flash cannot be used.
	Movie	8K: 1/8000sec. to 1/24 sec. 6.2K: 1/8000sec. to 1/24 sec. DCI4K/4K: 1/8000sec. to 1/4 sec. FHD: 1/8000sec. to 1/4 sec. *Cannot choose slower shutter speed than framerate for some settings.
	Synchronized shutter speed for flash	Mechanical shutter: 1/250sec. or slower Electronic shutter: 1/125sec. or slower
Continuous shooting		CH Electronic shutter Approx. 20fps (1.29x Crop) (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 202 frames, Compressed RAW + JPEG 129 frames, Lossless compressed RAW + JPEG 95 frames, Uncompressed RAW + JPEG 90 frames) CH Electronic shutter Approx. 13fps (1.29x Crop) (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW + JPEG 372 frames, Lossless compressed RAW + JPEG 361 frames, Uncompressed RAW + JPEG 223 frames) CH Electronic shutter Approx. 10fps (1.29x Crop) (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW + JPEG 1000+ frames, Lossless compressed RAW + JPEG 1000+ frames, Uncompressed RAW + JPEG 1000+ frames) CH Electronic shutter Approx. 13fps (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW+JPEG 131 frames, Lossless compressed RAW+JPEG 131 frames, Uncompressed RAW+JPEG 127 frames) CH Electronic shutter Approx. 8.9fps (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW+JPEG 769 frames, Lossless compressed RAW+JPEG 751 frames, Uncompressed RAW+JPEG 302 frames) CH Mechanical shutter Approx. 15fps (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 400 frames, Compressed RAW+JPEG 110 frames, Lossless compressed RAW+JPEG 108 frames, Uncompressed RAW+JPEG 104 frames) CH Mechanical shutter Approx. 10fps (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW+JPEG 512 frames, Lossless compressed RAW+JPEG 492 frames, Uncompressed RAW+JPEG 223 frames) CH Mechanical shutter Approx. 7.0fps (JPEG 1000+ frames, Compressed RAW 1000+ frames, Lossless compressed RAW 1000+ frames, Uncompressed RAW 1000+ frames, Compressed RAW+JPEG 1000+ frames, Lossless compressed RAW+JPEG 1000+ frames, Uncompressed RAW+JPEG 1000+ frames) Pre-shot Electronic shutter Approx. 20fps (1.29x Crop) (While half press 20 frames, After full press 1000+ frames) Pre-shot Electronic shutter Approx. 13fps (1.29x Crop) (While half press 13 frames, After full press 1000+ frames) Pre-shot Electronic shutter Approx. 10fps (1.29x Crop) (While half press 10 frames, After full press 1000+ frames) Pre-shot Electronic shutter Approx. 13fps (While half press 13 frames, After full press 1000+ frames) No. of recordable frames are calculated based on CFexpress Type B card in a cold start Recordable frames depends on recording media *Speed of continuous shooting depends on shooting environment and shooting frames
Drive Mode	AE Bracketing	2 frames / 3 frames / 5 frames / 7 frames / 9 frames *by 1/3EV step, up to ±3EV steps
	Filmsimulation bracketing	Any 3 types of film simulation selectable
	Dynamic Range Bracketing	100% / 200% / 400%
	ISO sensitivity Bracketing	±1/3EV / ±2/3EV / ±1EV
	White Balance Bracketing	±1 / ±2 / ±3
	Focus Bracketing	AUTO / MANUAL
	Multiple Exposure	Yes (Max. 9 frames) / Additive / Average / Bright / Dark
	HDR Mode	AUTO / 200% / 400% / 800% / 800% +
	Advanced filter	Toy camera / Miniature / Pop color / High-key / Low-key / Dynamic tone / Soft focus / Partial color (Red / Orange / Yellow / Green / Blue / Purple)
	Pixel Shift Multi Shot	Yes
Focus	Mode	Single AF / Continuous AF / MF
	Type	Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)
	Low-light Performance	Contrast: -4.0EV XF50mmF1.0 attached Phase Detection: -7.0EV XF50mmF1.0 attached
	AF frame selection	Single point AF: 13x9 / 25x17 (Changeable size of AF frame) Zone AF: 3x3 / 5x5 / 7x7 from 117 areas on 13×9 grid Wide/Tracking AF: Yes (AF-S: Wide / AF-C: Tracking) All: Yes
	Face/eye detection	Yes
	Subject detection	Yes (Animal/Bird/Automobile/Motorcycle&Bike/Airplane/Train)
Flash	EF-X8	Guide Number: approx. 11 (ISO200?m) / approx. 8 (ISO100?m) Sync. Mode: 1st Curtain / 2nd Curtain Flash Mode: TTL (TTL AUTO / STANDARD / SLOW SYNC. ) / MANUAL / COMMANDER / OFF
	Shoe mount flash	Sync. Mode: 1st Curtain / 2nd Curtain / AUTO FP (HSS) Flash Mode: TTL (TTL AUTO / STANDARD / SLOW SYNC. ) / MANUAL / MULTI *When EF-X500 is set / OFF
	Synchronized terminal	Sync. Mode: 1st Curtain / 2nd Curtain Flash Mode: MANUAL
Hot shoe		Yes (Dedicated TTL Flash compatible)
Viewfinder		EVF: 0.5 inch OLED Color Viewfinder, Approx. 5.76 million dots Coverage of Viewing Area vs. Capturing Area: Approx. 100% Eyepoint: Approx. 24mm (from the Rear End of the Camera's Eyepiece) Diopter Adjustment: -5?+3m-1 Magnification: 0.80x with 50mm Lens (35mm Equivalent) at infinity and Diopter set to -1.0m-1 Diagonal Angle of View: approx. 40° (Horizontal angle of view: approx. 32° ) Built-In Eye Sensor
LCD monitor		3.0 inch vari-angle Touch Screen Color LCD Monitor Aspect Ratio: 3:2 Dots: Approx. 1.62 million dots
Touch Screen Mode	Shooting Mode	Shooting, AF, Focus Area, OFF, Double Tap Setting (ON/OFF), Touch Function Setting (ON/OFF), Touch Zoom (ON/OFF), EVF Touch Screen Area Setting
	Playback Mode	Swipe, Pinch-in / Pinch-out, Double-tap, Drag
Sub LCD monitor		1.28 inch Monochrome LCD Monitor Aspect Ratio: 1:1 Dots: 128x128-dot
Movie recording	File format	MOV: Apple ProRes 422 HQ, Linear PCM (Stereo sound 24bit / 48KHz sampling) Apple ProRes 422, Linear PCM (Stereo sound 24bit / 48KHz sampling) Apple ProRes 422 LT, Linear PCM (Stereo sound 24bit / 48KHz sampling) HEVC/H.265, Linear PCM (Stereo sound 24bit / 48KHz sampling) MPEG-4 AVC/H.264, Linear PCM (Stereo sound 24bit / 48KHz sampling) MP4: MPEG-4 AVC/H.264, AAC
	Movie compression	All Intra / Long GOP
	File size Frame rate Bitrate	[8K(16:9)] 7680 x 4320?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [6.2K(16:9)] 6240 x 3510?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [DCI4K HQ(17:9)] 4096 x 2160?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [4K HQ(16:9)] 3840 x 2160?29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [DCI4K(17:9)] 4096 x 2160?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [4K(16:9)] 3840 x 2160?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [Full HD(17:9)] 2048 x 1080?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [Full HD(16:9)] 1920 x 1080?59.94p/50p/29.97p/25p/24p/23.98p?720Mbps/360Mbps/200Mbps/100Mbps/50Mbps [Full HD(17:9) High speed rec.] 2048 x 1080?240p/200p/120p/100p?720Mbps(recording)/360Mbps(recording)/200Mbps(recording) [Full HD(16:9) High speed rec.] 1920 x 1080?240p/200p/120p/100p?720Mbps(recording)/360Mbps(recording)/200Mbps(recording) For recording movies, use a CFexpress Type B card or SD memory card with UHS Speed Class 3 or higher. For recording movies in 360Mbps, use a CFexpress Type B card or SD memory card with Video Speed Class 60 or higher. For recording movies in 720Mbps, use a CFexpress Type B card or SD memory card with Video Speed Class 90 or higher. Selectable bitrate will be changed depends on the setting. Apple ProRes codec can be only recorded to CFexpress Type B card Bitrate for Apple ProRes codec is not selectable. *Recording time can become short depending on the temperature and/or shooting conditions
Film simulation mode		19 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, Classic Neg., Nostalgic Neg., ETERNA/Cinema, ETERNA BLEACH BYPASS, ACROS, ACROS + Ye Filter, ACROS + R Filter, ACROS + G Filter, Black & White, Black & White + Ye Filter, Black & White + R Filter, Black & White + G Filter, Sepia)
Monochromatic Color		Yes
Grain Effect	Roughness	STRONG, WEAK, OFF
	Size	LARGE, SMALL
Color Chrome Effect		STRONG, WEAK, OFF
Color chrome Blue		STRONG, WEAK, OFF
Smooth Skin Effect		STRONG, WEAK, OFF
Dynamic range setting	Still	AUTO / 100? / 200? / 400? ISO restriction: DR100%: No limit?DR200%: ISO250 or more?DR400%: ISO500 or more
	Movie	100? / 200? / 400? ISO restriction: DR100%: No limit?DR200%: ISO250 or more?DR400%: ISO500 or more
White balance	Auto	White Priority / Auto / Ambience Priority
	Custom	Custom1 - 3
	Color temperature selection	2500K-10000K
	Preset	Daylight / Shade / Fluorescent Light-1 / Fluorescent Light-2 / Fluorescent Light-3 / Incandescent Light / Underwater
Clarity setting		±5 steps
Self-timer		10sec. / 2sec.
Interval timer shooting		Yes (Setting : Interval, Number of shots, Starting time, Interval timer shooting exposure smoothing)
Wireless transmitter	Standard	IEEE802.11a/b/g/n/ac (standard wireless protocol)
	Encryption	WPA/WPA2 mixed mode, WPA3
	Access mode	Infrastructure
Bluetooth®	Standartd	Bluetooth Ver. 4.2 (Bluetooth low energy)
	Operating frequency (Center frequency)	2402 - 2480MHz
Terminal	Digital interface	USB Type-C (USB3.2 Gen2x1)
	HDMI output	HDMI connector (Type A)
	Others	ø3.5mm, stereo mini connector (Microphone) ø3.5mm, stereo mini connector (Headphone) ø2.5mm, Remote Release Connector Hot shoe Synchronized terninal
Power supply		NP-W235 Li-ion battery (included)
	Battery life for still images^*2	Economy Mode: Approx. 680 frames Normal Mode: Approx. 540 frames *When XF35mmF1.4 R is set
	Actual battery life of movie capture^*2	8K: Approx. 70min. (29.97p) 4K: Approx. 75min. (59.94p) Full HD: Approx. 85min. (59.94p), Approx. 90min. (120P) *Face detection is set to OFF
	Continuance battery life of movie capture^*2	8K: Approx. 100min. (29.97p) 4K: Approx. 120min. (59.94p) Full HD: Approx. 140min. (59.94p) *Face detection is set to OFF
Dimensions		Width: 136.3mm Height: 92.9mm Depth: 84.6mm (Minimum Depth: 42.8mm)
Weight		including battery and memory card: Approx. 660g excluding battery and memory card: Approx. 579g
Operation Environment	Operating Temperature	-10? - +40?
	Operating Humidity	10% - 80% (no condensation)
Starting up period		Approx. 0.49sec.
Accessories included		Li-ion battery NP-W235 AC power adapter AC-5VJ Plug adapter USB cable Shoulder strap Body cap Hot shoe cover File transmitter/vertical battery grip connector cover Memory card slot cover Sync terminal cover Cooling fan connector cover Cable protector Owner's manual

scroll

*1 Exif 2.32 is a digital camera file format that contains a variety of shooting information for optimal printing
*2 Approximate number of frames or movie recording time that can be taken with a fully-charged based on CIPA Standard.

Movie Specification

Media Rec (CFexpress Type B card / SD memory card)

Resolution/Aspect	Size	Frame rate	File format/Compression	Bit rate*2	Bit depth	HDMI outupt Resolution(Frame rate)/Sampling/Bit depth	Crop Magnification
Resolution/Aspect	Size	Frame rate	File format/Compression	Bit rate*2	Bit depth	HDMI outupt Resolution(Frame rate)/Sampling/Bit depth	DIS ON	DIS OFF
8K 16:9	7680 x 4320	29.97p 25.00p 24.00p 23.98p	ProRes 422 HQ MOV*1	3520Mbps(29.97p)*3	10bit	FHD 4:2:2 10bit*4	Not possible	1.0x
			ProRes 422 MOV*1	2352Mbps(29.97p)*3
			ProRes 422 LT MOV*1	1632Mbps(29.97p)*3
			H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV	720Mbps 360Mbps		FHD 4:2:2 10bit (When H.265 All-Intra 4:2:2 MOV selected)4 4K 4:2:2 10bit (When H.265 All-Intra 4:2:0 MOV selected)4	Not possible	1.0x
			H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV	720Mbps 360Mbps 200Mbps 100Mbps 50Mbps		FHD 4:2:2 10bit (When H.265 Long GOP 4:2:2 MOV selected)4 4K 4:2:2 10bit (When H.265 Long GOP 4:2:0 MOV selected)4	Not possible	1.0x
6.2K 16:9	6240 x 3510	29.97p 25.00p 24.00p 23.98p	ProRes 422 HQ MOV*1	2324Mbps(29.97p)*3	10bit	FHD 4:2:2 10bit*4	Not possible	1.0x
			ProRes 422 MOV*1	1553Mbps(29.97p)*3
			ProRes 422 LT MOV*1	1077Mbps(29.97p)*3
			H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV	720Mbps 360Mbps		FHD 4:2:2 10bit (When H.265 All-Intra 4:2:2 MOV selected)4 4K 4:2:2 10bit (When H.265 All-Intra 4:2:0 MOV selected)4	Not possible	1.0x
			H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV	720Mbps 360Mbps 200Mbps 100Mbps 50Mbps		FHD 4:2:2 10bit (When H.265 Long GOP 4:2:2 MOV selected)4 4K 4:2:2 10bit (When H.265 Long GOP 4:2:0 MOV selected)4	Not possible	1.0x
DCI4K HQ 17:9 4K HQ 16:9	4096 x 2160 3840 x 2160	29.97p 25.00p 24.00p 23.98p	ProRes 422 HQ MOV*1	939Mbps(DCI 4K 29.97p)*3	10bit	DCI4K/4K 4:2:2 10bit	Not possible	1.0x
			ProRes 422 MOV*1	627Mbps(DCI 4K 29.97p)*3
			ProRes 422 LT MOV*1	435Mbps(DCI4K 29.97p)*3
			H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV	720Mbps 360Mbps			Not possible	1.0x
			H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV	720Mbps 360Mbps 200Mbps 100Mbps 50Mbps			Not possible	1.0x
			H.264 All-Intra 4:2:0 MOV	360Mbps	8bit	DCI4K/4K 4:2:2 8bit	Not possible	1.0x
			H.264 Long GOP 4:2:0 MOV H.264 Long GOP 4:2:0 MP4	360Mbps 200Mbps 100Mbps 50Mbps	8bit	DCI4K/4K 4:2:2 8bit	Not possible	1.0x
DCI4K 17:9 4K 16:9	4096 x 2160 3840 x 2160	59.94p 50.00p 29.97p 25.00p 24.00p 23.98p	ProRes 422 HQ MOV*1	1877Mbps(DCI4K 59.94p)*3	10bit	DCI4K/4K 4:2:2 10bit	Not possible	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
			ProRes 422 MOV*1	1254Mbps(DCI4K 59.94p)*3
			ProRes 422 LT MOV*1	870Mbps(DCI4K 59.94p)*3
			H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV	720Mbps 360Mbps			1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
			H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV	720Mbps 360Mbps 200Mbps 100Mbps 50Mbps			1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
			H.264 All-Intra 4:2:0 MOV	360Mbps	8bit	DCI4K/4K 4:2:2 8bit	1.1x	1.0x
			H.264 Long GOP 4:2:0 MOV H.264 Long GOP 4:2:0 MP4	360Mbps 200Mbps 100Mbps 50Mbps	8bit	DCI4K/4K 4:2:2 8bit	1.1x	1.0x
FHD 17:9 FHD 16:9	2048 x 1080 1920 x 1080	59.94p 50.00p 29.97p 25.00p 24.00p 23.98p	ProRes 422 HQ MOV*1	440Mbps(FHD16:9 59.94p)*3	10bit	FHD 4:2:2 10bit*5	Not possible	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
			ProRes 422 MOV*1	294Mbps(FHD16:9 59.94p)*3
			ProRes 422 LT MOV*1	204Mbps(FHD16:9 59.94p)*3
			H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV	720Mbps 360Mbps			1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
			H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV	720Mbps 360Mbps 200Mbps 100Mbps 50Mbps			1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
			H.264 All-Intra 4:2:0 MOV	360Mbps	8bit	FHD 4:2:2 8bit*5	1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
			H.264 Long GOP 4:2:0 MOV H.264 Long GOP 4:2:0 MP4	360Mbps 200Mbps 100Mbps 50Mbps	8bit	FHD 4:2:2 8bit*5	1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
High speed FHD 17:9 FHD 16:9	2048 x 1080 1920 x 1080	240fps(4×/8×/10×) 200fps(4×/8×) 120p (2x/4x/5x) 100p (2x/4x)	ProRes 422 HQ MOV*1	1760Mbps (when recording FHD16:9 240p)*3	10bit	FHD(59.94p) 4:2:2 10bit*6	Not possible	1.23x
			ProRes 422 MOV*1	1176Mbps (when recording FHD16:9 240p)*3
			ProRes 422 LT MOV*1	816Mbps (when recording FHD16:9 240p)*3
			H.265 All-Intra 4:2:2 MOV H.265 All-Intra 4:2:0 MOV	720Mbps (when recording) 360Mbps (when recording)
			H.265 Long GOP 4:2:2 MOV H.265 Long GOP 4:2:0 MOV	720Mbps (when recording) 360Mbps (when recording) 200Mbps (when recording)
			H.264 All-Intra 4:2:0 MOV	360Mbps (when recording)	8bit	FHD(59.94p) 4:2:2 8bit*6
			H.264 Long GOP 4:2:0 MOV H.264 Long GOP 4:2:0 MP4	360Mbps (when recording) 200Mbps (when recording)	8bit	FHD(59.94p) 4:2:2 8bit*6

scroll

HDMI Output

Resolution/Aspect	Size	Frame rate	HDMI outupt Resolution/Sampling/Bit depth	Crop Magnification
Resolution/Aspect	Size	Frame rate	HDMI outupt Resolution/Sampling/Bit depth	DIS ON	DIS OFF
8K 16:9	7680 x 4320	29.97p 25.00p 24.00p 23.98p	8K 4:2:2 10bit	Not possible	1.0x
6.2K 16:9	6240 x 3510	29.97p 25.00p 24.00p 23.98p	FHD 4:2:2 10bit*4	Not possible	1.0x
DCI4K HQ 17:9 4K HQ 16:9	4096 x 2160 3840 x 2160	29.97p 25.00p 24.00p 23.98p	DCI4K/4K 4:2:2 10bit	Not possible	1.0x
DCI4K 17:9 4K 16:9	4096 x 2160 3840 x 2160	59.94p 50.00p 29.97p 25.00p 24.00p 23.98p	DCI4K/4K 4:2:2 10bit	1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x
FHD 17:9 FHD 16:9	2048 x 1080 1920 x 1080	59.94p 50.00p 29.97p 25.00p 24.00p 23.98p	FHD 4:2:2 10bit?*5	1.1x	59.94p/50.00p:1.14x 29.97p/25.00p/24.00p/23.98p:1.0x

scroll

HDMI Output (High speed REC HDMI ONLY?

Resolution/Aspect	Size	Frame rate	HDMI outupt Resolution(Frame rate)/Sampling/Bit depth			Crop Magnification
Resolution/Aspect	Size	Frame rate	HDMI outupt Resolution(Frame rate)/Sampling/Bit depth			DIS ON	DIS OFF
FHD 16:9	1920 x 1080	120p 100p	FHD(120p/100p) 4:2:2 10bit			??	1.23x

scroll

HDMI RAW Output

Resolution/Aspect	Size	Frame rate		Crop Magnification
Resolution/Aspect	Size	Frame rate		DIS ON	DIS OFF
8K 16:9	7680 x 4320	29.97p 25.00p 24.00p 23.98p		??	1.0x

scroll

*1 ProRes codec can be recorded to only CFexpress Type B card
*2 Bit rate will be changed depend on the subject
*3 Bit rate for ProRes codec can not be selected
*4 The resolution from HDMI output is different from selected setting
*5 When the aspect ratio is not 16:9, the image is output in 16:9 with a black band.
*6 The frame rate from HDMI output is different from selected setting
