Canon EOS C80 Body Camera

• Sensor
  Full Frame Back-Side Illuminated (BSI) CMOS sensor
• Filter
  RGB primary color filter (Bayer array)
• Sensor Modes
  Full Frame / Super 35mm (crop)
• Total Pixels
  Approx. 26.67 megapixels (6202x4300)
• Effective Pixels
  Approx. 19.05 megapixels (6008x3170)?When 6000x3164 / 4096x2160 / 2048x1080 is selected as the resolution
  Approx. 17.86 megapixels (5634x3170)? When 3840x2160 / 1920x1080 is selected as the resolution
• Effective Sensor Screen Size
  Full Frame:
  36.0 x 19.0 mm (40.7 mm on the diagonal)? When 6000x3164 / 4096x2160 / 2048x1080 is selected as the resolution
  33.8 x 19.0 mm (38.7 mm on the diagonal)? When 3840x2160 / 1920x1080 is selected as the resolution
• Dynamic Range
  Canon Log 2: 1600% / 16 stops (at ISO 800)
  Canon Log 3: 1600% / 14 stops (at ISO 800)
  Base ISO: 800 / 3200 / 128001

Image Processor

• Type
  DIGIC DV7

Lens

• Lens Mount
  Canon RF mount
  PL mount support via PL-RF Mount Adapter
  EF mount support via EF-EOS R Mount Adapter
• Lens Magnification Factor
  Full frame;
  6000x3164, 4096x2160 or 2048x1080: Actual focal length x Approx. 1.06
  3840x2160 or 1920x1080: Actual focal length x Approx. 1.12

  Super 35mm (Crop);
  4368x2304, 4096x2160 or 2048x1080: Actual focal length x Approx.1.46
  3840x2160 or 1920x1080: Actual focal length x Approx.1.54
• Digital Lens Correction
  Peripheral Illumination Correction
  Chromatic Aberration Correction
  Diffraction Correction
  Distortion Correction (RF lenses only)
• ND Filter
  2, 4 or 6 Stops. Up to 10 stops via built in ND filter system (in extended mode)
• Iris Control (EF Mount Lenses)
  1/2-stop, 1/3-stop or FINE control
  Auto Iris
• Cooke /i Technology™ Support
  Only when equipped with PL-RF Mount Adapter
• Anamorphic Lens Support
  x2.0 / x1.8 / x1.3
• Image Stabilization System
  5-Axis Combination IS (Optical and Digital) with supported lenses
  Digital 5-Axis IS for non IS lenses.

Recording

• Internal Recording Media
  2x SD Card (SD / SDHC / SDXC)
• Recording Time
  Cinema RAW Light LT: 6000 x 3164 576 Mbps: approx. 118 Mins
  Cinema RAW Light ST: 4368 x 2304 470 Mbps: approx. 145 Mins
  XF-AVC: 4096x2160 500 Mbps: approx. 136 Mins
  XF-AVC S: 4096x2160 500 Mbps: approx. 136 Mins
  XF-HEVC S: 4096x2160 135 Mbps: approx. 505 Mins2
• Recording Formats
  Cinema RAW Light (CRM), XF-AVC (MXF), XF-AVC S (MP4), XF-HEVC S (MP4)
• Relay Recording
  Yes3
• Double Slot (Simultaneous) Recording
  Yes4
• Simultaneous Recording in Multiple Formats
  Yes
• System Frequency / Frame Rates
  59.94Hz mode (59.94P / 59.94i / 29.97P / 23.98P)
  50.00Hz mode (50.00P / 50.00i / 25.00P)
  24.00 Hz mode (24.00P)
• Cinema RAW Light Bit Rate / Bit Depth (PAL)
  12-bit Cinema RAW Light LT:
  FF / 6000 x 3164 / 25P [576 Mbps]
  S35 / 4368 x 2304 / 50P [611 Mbps]
  S35 / 4368 x 2304 / 25P [306 Mbps]

  12-bit Cinema RAW Light ST:
  S35 / 4368 x 2304 / 25P [470 Mbps]
• XF-AVC Recording Bit Rate / Sampling (PAL / MXF)
  4:2:2 10-bit (Intra-frame):
  4096x2160 or 3840x2160 / 50P [500 Mbps]
  4096x2160 or 3840x2160 / 25P [500 / 375 / 250 Mbps]
  2048x1080 or 1920x1080 / 50P [250 Mbps]
  2048x1080 or 1920x1080 / 50i [125 Mbps]
  2048x1080 or 1920x1080 / 25P [125 Mbps]

  4:2:2 10-bit (Long GOP):
  4096x2160 or 3840x2160 / 50P [250 Mbps]
  4096x2160 or 3840x2160 / 25P [150 Mbps]
  2048x1080 or 1920x1080 / 50P [50 Mbps]
  2048x1080 or 1920x1080 / 50i [50 / 25 Mbps]
  2048x1080 or 1920x1080 / 25P [50 Mbps]
• XF-AVC S Recording Bit Rate / Sampling (PAL / MP4)
  4:2:2 10-bit (Intra-frame):
  4096x2160 or 3840x2160 / 50P [500 Mbps]
  4096x2160 or 3840x2160 / 25P [500 / 375 / 250 Mbps]
  2048x1080 or 1920x1080 / 50P [250 Mbps]
  2048x1080 or 1920x1080 / 25P [125 Mbps]

  4:2:2 10-bit (Long GOP):
  4096x2160 or 3840x2160 / 50P [250 Mbps]
  4096x2160 or 3840x2160 / 25P [150 Mbps]
  2048x1080 or 1920x1080 / 50P [50 Mbps]
  2048x1080 or 1920x1080 / 25P [50 Mbps]

  4:2:0 8-bit (Long GOP):
  4096x2160 or 3840x2160 / 50P [150 Mbps]
  4096x2160 or 3840x2160 / 25P [100 Mbps]
  2048x1080 or 1920x1080 / 50P [35 Mbps]
  2048x1080 or 1920x1080 / 25P [35 Mbps]
• XF-HEVC S Recording Bit Rate / Sampling (PAL / MP4)
  4:2:2 10-bit (Long GOP):
  4096x2160 or 3840x2160 / 50P [225 Mbps]
  4096x2160 or 3840x2160 / 25P [135 Mbps]
  2048x1080 or 1920x1080 / 50P [50 Mbps]
  2048x1080 or 1920x1080 / 25P [50 Mbps]

  4:2:0 10-bit (Long GOP):
  4096x2160 or 3840x2160 / 50P [150 Mbps]
  4096x2160 or 3840x2160 / 25P [100 Mbps]
  2048x1080 or 1920x1080 / 50P [35 Mbps]
  2048x1080 or 1920x1080 / 25P [35 Mbps]
• Proxy Recording Bit Rate / Sampling (PAL)
  4:2:0 8-bit (Long GOP):
  2048x1080 or 1920x1080 [35 / 16 / 9 Mbps]
  1280 x 720 [6 Mbps]

  4:2:0 10-bit (Long GOP):
  2048x1080 or 1920x1080 [16 / 9 Mbps]5
• Slow / Fast Motion
  6K RAW: up to 30FPS
  4K recording: up to 120FPS (Long GOP) / 60FPS (Intra-frame)
  2K recording: up to 180FPS (Long GOP) / 120FPS (Intra-frame)
• Interval Record
  Yes
• Frame Record
  Yes
• Pre Record (Cache Record)
  3 Seconds6
• Digital Tele-converter
  1.5x, 2x, 2.5x, 3x, Off
• Photo Storage Media
  SD Card
• Photo Recording Size
  4096x2160 / 3840x2160 / 2048x1080 / 1920x10807

System

• Display Type
  3.5 inch LCD Touch Panel
• Display Resolution
  approx. 2.76 million dots (1280xRGBx720)
• Display Touch Screen Functions
  Focus Point Selection
  Touch Screen UI for Shooting Settings
• OSD for Vertical Shooting
  Yes
• Wave Form Monitor
  Yes (Line / Line + Spot / RGB Parade / YPrPb Parade)
• False Colour Display (Exposure Indication)
  Yes (6 Colour Index)
• Colour Bars
  SMPTE / EBU / ARIB
• Peaking
  Peaking 1, Peaking 2 (Colour, Gain, Frequency customisable)
• Zebra
  Level 1; Level 2; Both
• Markers
  On/Off selectable: centre, horizontal / verstical, grid, aspect, safe area and user marker. Colour selectable

EVF

• Built-In EVF
  No

Inputs / Outputs

• Audio In
  2x Mini XLR 3-pin connector
  1x 3.5 mm stereo mini jack
  Built in Stereo microphones on camera body
• Headphone Output
  1x 3.5mm stereo mini jack
• Video Monitor Output
  No
• HDMI
  1x HDMI (Type-A) (6K RAW output available8)
• USB
  1x USB-C Data Terminal (USB3.2 Gen1)
• SDI Output
  1x 12G-SDI Output (BNC)
• Time Code
  1x BNC Terminal (Input / Output)
• Genlock
  No
• Sync
  No
• DC Input
  1x 24V DC jack
• Multi-Accessory Shoe
  Yes (via camera body)
• Remote Control Terminal
  1x 2.5 mm stereo mini jack
• Lens Terminal
  No
• Ethernet Terminal
  1x RJ45 Connector (1000BASE-T compatible)
• Grip
  No
• IP Streaming / FTP
  IP Streaming via Ethernet / Wi-Fi connection
  9 Mbps / 4 Mbps: 1920 x 1080 (59.94p / 59.94i / 50.00p / 50.00i)
  UDP / RTP / SRT / RTP+FEC / RTSP+RTP
• User LUT Input
  Yes, in-built LUTs available for monitoring.
  Custom LUTs can be applied directly to internal recordings via Look File function (compatible with 17 or 33 grid .cube files)
• Video Connector
  No
• Tally Signal
  Yes, via Wi-Fi or Ethernet using XC Protocol
• Return Signal Input
  No
• Default Function Button Settings
  1. WB
  2. SET WB
  3. PEAKING
  4. WFM
  5. DISP
  6. ZEBRA
  7. AUTO IRIS
  8. MAGN.
  9. FUNC
  10. (unassigned)
  11. (unassigned)
  12. AF LOCK
  13. AUDIO STATUS
• User Assignable Buttons
  13x (Body)

Miscellaneous

• Tally Lamp
  Yes, 1x
• Custom Dial
  Yes, 3x
• Software Application Support
  Cinema RAW Development
  XF Utility
  EOS VR Utility
  Remote Camera Control Application
  RAW Plugin for Avid Media Access
  RAW Plugin for Final Cut Pro
  XF Plugin for Avid Media Access
  EOS VR Plugin for Adobe Premiere Pro
  CV Metadata Plugin for Adobe After Effects
  Live Link Plugin for Unreal Engine
  CV Metadata Extraction Tool
  MP4 Join Tool
  HEVC Activator
  Frame.io Camera to Cloud
• Smartphone Application Support
  Canon Multi-Camera Control
  Content Transfer Professional
  Browser Remote Control

Exposure

• Exposure Metering
  Standard / Spotlight / Backlight
• Exposure Compensation
  AE shift function available. Target value (±8 steps from center)
• Auto Exposure Mode
  Auto Iris / Auto ISO
• Push Auto Iris
  Yes
• Exposure Lock
  No
• Auto Gain Control Setting
  Yes
• ISO Sensitivity
  1-Stop Display:
  100* / 160** / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200* / 102400*
  1/3-Stop Display:
  100* / 125* / 160 / 200 / 250 / 320 / 400 / 500 / 640 / 800 / 1000 / 1250 / 1600 / 2000 / 2500 / 3200 / 4000 / 5000 / 6400 / 8000 / 10000 / 12800 / 16000 / 20000 / 25600 / 32000* / 40000* / 51200* / 64000* / 80000* / 102400*9
  *when ISO Extended Range is set to ON
  **when ISO Extended Range is set to OFF
• Auto Focus System
  Dual Pixel CMOS AF II + EOS iTR AF X
• AF Frame Sizes
  Full: approx. 100% (Vertical) x approx. 100% (Horizontal)
  Large Zone (Vertical): Video display range approx. 97% (Vertical) x 25% (Horizontal)
  Large Zone (Horizontal): Video display range approx. 43% (Vertical) x 76% (Horizontal)
  Zone: Video display range approx. 43% (Vertical) x 25% (Horizontal)
  Small Zone: Video display range approx. 15.9% (Vertical) x 11.8% (Horizontal)
• Auto Focus Modes
  Continuous AF / One-Shot AF
• Face Detection AF
  Yes (Eye / Face / Head / Body)
• Animal Detection AF
  Yes (Dogs / Cats)
• Focus Guide
  Yes, with compatible Canon lenses
• Gain Setting
  -6dB*, -3dB*, -2dB**?42dB, 45dB*, 48dB*, 51dB*, 54dB*10
  *when ISO Extended Range is set to ON
  **when ISO Extended Range is set to OFF

Shutter

• Control Modes
  Speed / Angle / Clear Scan / Slow Shutter
• Shutter Speed
  1/1?1/2000 (total of 47 settings)
• Shutter Angle
  11.25º to 360º depending on frame rate
• Slow Shutter (SLS)
  1/3, 1/4, 1/6, 1/8, 1/12, 1/15, 1/25, 1/30 depending on frame rate
• Clear Scan
  23.97 Hz?1971 Hz depending on sensor mode / frame rate

Custom Picture

• Stored Configurations
  C1: Canon 709
  C2: Canon Log 2
  C3: Canon Log 3
  C4: BT.709 Wide DR
  C5: BT.709 Standard
  C6: PQ
  C7: HLG
  C8: EOS Standard
  C9: EOS Neutral
  C10: User10 ?User20
• HDR-HLG Profile
  BT.2100: Corresponds to ITU-R BT.2100
  Vivid: Corresponds to Traditional Colour in ITU-R BT.2390
• Colour Matrix
  Neutral: Accurate colour reproduction
  Production Camera: Colour reproduction for use in movie production
  Video: Colour reproduction with contrast for TV broadcasts.
• Image Adjustment Parameters
  Master Pedestal
  Master Black
  Black Gamma
  Low Key Saturation
  Knee
  Sharpness
  Noise Reduction
  Skin Detail
  Colour Matrix Tuning
  White Balance
  Colour Correction

Wi-Fi & GPS Specifications

• Wi-Fi (Optional Third Party Accessory)
  In-built (2.4 / 5GHz bands)
  Supporting 802.11a/b/g/n/ac
• GPS Information (Optional Accessory)
  Only when equipped with GP-E2 GPS Receiver

White Balance

• Auto
  Yes
• Preset
  Daylight (5600K), Tungsten (3200K), Kelvin (2000K-15000K, 100K intervals), Set A, Set B
• White Balance Shift
  -5 CC - +5 CC (Daylight / Tungsten)
  -20 CC - +20 CC (Kelvin)

Time Code

• Count Up System
  Regen / RecRun / Free Run / External / Frame Count

Audio

• Recording Format
  RAW / XF-AVC: Linear PCM (24-bit / 48 kHz, 4 channels)
  XF-AVC S / XF-HEVC S: Linear PCM (24-bit / 48 kHz, 4 channels) or MPEG2-AAC LC (16 bit 48kHz) 2 channels

Accessories

• Supplied
  Handle Unit
  BP-A30N Battery Pack
  CA-CP300 B Compact Power Adapter
  CG-A20 Battery Charger
  Microphone Holder
  SS-1200 Shoulder Strap
• Optional
  BP-A60N / BP-A30N Battery Pack
  BP-A30 / BP-A60 Battery Pack
  CG-A20 / CG-A10 Battery Charger
  PL-RF Mount Adapter
  EF-EOS R Mount Adapter
  EF-EOS R Control Ring Mount Adapter
  EF-EOS R Drop-In Filter Mount Adapter
  EF-EOS R 0.71x Mount Adapter
  Remote Camera Controller RC-V100
  Remote Camera Controller RC-IP100
  Remote Camera Controller RC-IP1000
  DM-E1D Multi-Function Shoe Directional Stereo Microphone
  OC-E4A Off-Camera Shoe Cord
  IFC-100U / IFC-400U Interface Cable
• Third Party Accessories
  Tascam CA-XLR2d XLR Microphone Adapter

Power Source

• Power Supply (Battery)
  BP-A30N (Supplied)
  BP-A60N / BP-A30 / BP-A60 (Optional)
• Power supply (Mains)
  DC IN 24V Terminal
• Power Consumption (Approx.)
  RAW LT, 6000x3164, 29.97P (14.5W)
  RAW LT, 4368x2304, 59.94P (18.2W)
  XF-AVC, 3840x2160, 59.94P (19.6W)
  XF-AVC, 2048x1080, 59.94P (17.9W)
• Recording Time (Approx.)
  With supplied BP-A30N battery pack:
  RAW LT, 6000x3164, 29.97P: 170 Mins (Full Frame)
  RAW LT, 4368x2304, 59.94P: 135 mins (Super35)
  XF-AVC, 3840x2160, 59.94P: 125 mins (Full Frame)
  XF-AVC, 2048x1080, 59.94P: 140 mins (Super35)

Physical Specifications

• Dimensions (Main Body Only)
  approx. 160 x 138 x 116 mm
• Weight (Body Only)
  approx. 1310g
• Weight (Accessories)
  Handle Unit: Approx. 155g
  BP-A30N Battery Pack: Approx. 243g
  CA-CP300 B Compact Power Adapter: Approx. 219g
  Battery Charger CG-A20: Approx. 145g
  Microphone Holder + 2 screws: Approx. 60g
• Operating Temperature Range
  Approx. 0 to 40°C, (85% relative humidity)
  Approx. -5 to 45°C, (60% relative humidity)
