Specification :
Superb light transmission due to Fujifilm's unique SUPER EBC FUJINON multi-coating on all light-transmitting surfaces including the lens elements and prisms. The ED lens elements effectively control the chromatic aberration and prism coating for a superior image resolution as well as contrast. This also allows for a much brighter field of view. The optimal placement of nine lens elements in seven groups controls distortion across the entire view from the center to the edges.
Contrast-rich image
Premium design features such as metal texturing amplifies users’ senses and operability. A slip resistant elastomeric material and ergonomically engineered easy-grip body shape allow for excellent stability when held in your hand. Long eye-relief for easy use even when wearing glasses.
Water and fog proof structure*1 and robust magnesium-alloy body. Water-repellant coating on both objective lenses and eyepieces. Optical filters*2 such as PL filters and nebula filters are usable by fitting into the front side of objective lenses.
HC 8 x 42 | HC 10 x 42 | |
---|---|---|
Magnification | 8 | 10 |
Objective lens diameter (mm) | 42 | 42 |
Field of view (°) | 8 | 6.5 |
Field of view at 1000m (m) | 136 | 114 |
Minimum objective distance (m)*1 | 2.0 | 2.0 |
Exit pupul diameter (mm) | 5.3 | 4.2 |
Eye relief (mm) | 18 | 16 |
Dioptric compensation (±mm) | ±4m-1 | ±4m-1 |
Pupil distance (mm) | 58-76 | 58-76 |
Length (mm) | 139 | 137 |
Width (mm) | 130 | 130 |
Height (mm) | 54 | 54 |
Weight (g) (w/o Battery) | 788 | 782 |
Filter diameter | M46×0.75 | M46×0.75 |
Operationg temperature | -10??+50? | -10??+50? |
Country of origin | Japan | Japan |
