Specification :
The FeelWorld LUT6S is designed with HDMI and SDI connections, LUT support, and a max brightness of 2600 cd/m² to allow a comprehensive video monitoring solution suitable for bright outdoor conditions. It's also built slim and compact so it can comfortably be used on the side of your gimbal and in other mobile applications, as well as on-camera using an included tilt-adjustable mounting arm.
The LUT6S features a 6" 1920 x 1080 touchscreen display and HDMI/SDI inputs and loop outputs as well as a 3.5mm headphone jack for audio monitoring on set. Work with up to DCI 4K30 resolution via the HDMI ports and 2K60 via SDI (SDI output supports up to 1080p60 only). An intuitive operating system is navigated with touch and swipe gestures and offers access to tools and functions such as built-in HDR and DeLog 3D LUTs, anamorphic de-squeeze, vectorscope, zoom, focus assist, and much more. The LUT6S also allows you to upload up to 50 3D LUTs via an SD card slot and keep them stored.
Power options include an integrated L-series battery plate and a DC power input port. There's also an auxiliary DC power output that allows you to run select cameras off the monitor's power supply. Batteries and cables are sold separately. To ensure proper heat dissipation, a fan on the rear of the monitor turns on automatically whenever backlight brightness reaches over 80. The LUT6S provides a 1/4"-20 mounting thread on the bottom and one on the right side.
Model | LUT6S |
Screen Size | 6" IPS |
Resolution | 1920x1080 pixels |
Pixel Pitch | 0.069 (L) x 0.069 (W) (mm) |
Aspect Ratio | 16:9 |
Brightness | 2600cd/m² |
Contrast Ratio | 1000:1 |
Backlight | LED |
Viewing Angle | 80°/80°(L/R) 80°/80°(U/D) |
1 X BNC | 3G-SDI |
1 X HDMI | HDMI |
1 X BNC | 3G-SDI |
1 X HDMI | HDMI |
1 X DC | Barrel (3.5mm outer, 1.1mm inner) barrel output for powering cameras via camera specific adaptor. |
Audio | 3.5mm Stereo Headphone |
720p (60/59.94/50/30/29.97/25/24/23.98) |
1080i(60/59.94/50) |
1080p (60/59.94/50/30/29.97/25/24/23.98) |
2048x1080i (60/59.94/50) |
2048x1080p (60/59.94/50/30/29.97/25/24/23.98) |
720p (60/59.94/50/30/29.97/25/24/23.98) |
1080i(60/59.94/50) |
1080p (60/59.94/50/30/29.97/25/24/23.98) |
480i/576i/480p/576p |
1080i (60/59.94/50) |
720p (60/59.94/50/30/29.97/25/24/23.98) |
1080p (60/59.94/50/30/29.97/25/24/23.98) |
3840x2160p (30/29.97/25/24/23.98) |
4096×2160p (30/29.97/25/24/23.98) |
Input Voltage | DC7?24V |
Power Consumption | ≤16W |
Working Temperature | -20°C~50°C |
Storage Temperature | -30°C~60°C |
Install Way | 1/4"-20 Thread Socket (Right, Bottom) |
Battery Plate | F970 Battery Plate |
Unit Size | 162Lx93.2Hx29D (mm) |
Unit Weight | 300g |
* Support 3D LUT Log to Rec.709, user 3D LUT Upload |
* Support Touch Menu |
* Support HDR monitoring |
* Parade (RGB, YUV, Y) |
* All Waves |
* Vector |
* RGB Histogram |
* Brightness Histogram |
* Embedded Audio |
* Peaking Focus (red, green, blue, white, yellow five peaking colors optional; 1~10 peaking level adjustable) |
* False Colors |
* Zebra Exposure (1%~100% adjustable) |
* Check Field (Red, Green, Blue, Gray) |
* Scan Mode (Under Scan, Over Scan) |
* Anamorphic Mode (1.25x, 1.33x, 1.5x, 2.0x, 2.0x mag) |
* Image Flip (H, V, H/V) |
* Image Freeze |
* Center Marker |
* Safety Marker (70%, 80%, 90%, 16:9, 16:10, 4:3, 5:4, 1.85:1, 2.35:1) |
* Ratio Marker (16:9, 16:10, 4:3, 1.85:1, 2.35:1) |
* Marker Color (red, green, blue, white, black, yellow) |
* Color Temperature Adjustment |
* Nine Grid |
* Zoom (100%~300%) |
* Aspect Ratio |
* Pixel to Pixel |
